Product Form Factor
Tower - 5U
Embedded Security
Trusted Platform Module (TPM 1.2) Security Chip
Front Accessible Bays Qty
1
CPU Upgradability
Upgradable
Installed Size
0 GB (installed) / 256 GB (max)
Slots
16 (Total) / 16 (empty)
RAM Supported
PC4-17000 - 256 GB Load-Reduced ¦ PC4-17000 - 256 GB registered
Type
1 x RAID - integrated
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HP Dynamic Smart Array B140i
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Interface (Bus) Type
PCI Express x2
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
HP 331i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Bays
1 (total) / 1 (free) x external 5.25" ¦ 4 (total) / 4 (free) x hot-swap 3.5" LFF
Slots
16 (total) / 16 (free) x DIMM 288-pin ¦ 2 (total) / 2 (free) x CPU ¦ 3 PCIe 3.0 x8 - half-length, full-height ¦ 1 PCIe 3.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (2 processors must be installed) ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height (2 processors must be installed) ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces
1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 5 x USB 3.0 (2 front, 2 rear, 1 internal) ¦ 3 x USB 2.0 (2 rear, 1 internal)
Features
Administrator password, power-on password, serial port I/O control, Setup Password, UEFI BIOS
Compliant Standards
ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, ASHRAE, CNS 13438
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris, Canonical Ubuntu
Service & Support
Limited warranty - parts - 3 years - response time: next business day ¦ Limited warranty - parts and labour - 1 year - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
