EAN / GTIN:
4711081441205
Product Form Factor
Rack-mountable - 1U
Front Accessible Bays Qty
1
CPU Upgradability
Upgradable
CPU Socket
LGA1200 Socket
Installed Size
0 GB (installed) / 128 GB (max)
Slots
4 (Total) / 4 (empty)
Features
Unbuffered, dual channel memory architecture
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Graphics Processor
ASPEED AST2600
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
2 x Intel I210-AT
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Bays
1 (total) / 1 (free) x external 5.25" Slim Line ¦ 4 (total) / 4 (free) x hot-swap 3.5"
Slots
1 (total) / 1 (free) x PCIe 4.0 x16 - half-length, full-height (x16 mode (x8 mode if PCI Express 4.0 x8 slot is occupied)) ¦ 1 (total) / 1 (free) x PCIe 4.0 x8 - half-length, half-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x4
Interfaces
2 x USB 3.2 Gen 1 (2 in front) ¦ 2 x LAN (Gigabit Ethernet) - RJ-45 ¦ 2 x USB 3.2 Gen 2 ¦ 1 x management - RJ-45 ¦ 2 x VGA (1 front, 1 rear) ¦ 1 x HDMI ¦ 1 x serial
Included Accessories
VROC module
Compliant Standards
FCC Class A certified, BSMI
Voltage Required
AC 100-240 V (50 - 60 Hz)
80 PLUS Certification
80 PLUS Gold
Operating System / Software
OS Provided
No operating system
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
