Product Form Factor
Rack-mountable - 1U
Embedded Security
Trusted Platform Module (TPM 1.2) Security Chip
CPU Upgradability
Upgradable
CPU Socket
FCLGA2011-v3 Socket
Installed Size
0 GB (installed) / 256 GB (max)
Technology
DDR4 SDRAM - Advanced ECC
Slots
8 (Total) / 8 (empty)
Features
Registered, Load-Reduced DIMM (LRDIMM)
RAM Supported
256 GB registered - Advanced ECC ¦ 256 GB Load-Reduced - Advanced ECC
Type
1 x RAID - integrated
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HP Dynamic Smart Array B140i
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Graphics Processor
Matrox G200eH2
Interface (Bus) Type
PCI Express 2.0 x2
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
HP NC361i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab, IEEE 802.1as, IEEE 802.3az
Bays
4 (total) / 4 (free) x hot-swap 3.5" LFF
Slots
1 (total) / 1 (free) x PCIe 3.0 x16 - low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - low-profile ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces
2 x LAN (Gigabit Ethernet) ¦ 1 x VGA ¦ 1 x USB 2.0 (1 in front) ¦ 3 x USB 3.0 (2 rear, 1 internal)
Features
Administrator password, power-on password, UEFI BIOS
Compliant Standards
ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, ASHRAE, CNS 13438
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux
Service & Support
Limited warranty - parts and labour - 1 year - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
