EAN / GTIN:
4514953962040
Product Form Factor
Rack-mountable - 5U
Embedded Security
Trusted Platform Module (TPM 1.2) Security Chip
Front Accessible Bays Qty
1
Localisation
Region: Europe
CPU Upgradability
Upgradable
Cache Per Processor
25 MB
Installed Size
32 GB (installed) / 384 GB (max)
Technology
DDR4 SDRAM - Advanced ECC
Effective Memory Speed
2400 MHz
Rated Memory Speed
2400 MHz
Memory Specification Compliance
PC4-19200
Slots
24 (Total) / 22 (empty)
Features
Registered, Online Spare Memory, quad channel memory architecture, HP SmartMemory
Configuration Features
2 x 16 GB
RAM Supported
PC4-17000 - 768 GB Load-Reduced ¦ PC4-17000 - 384 GB registered
Type
1 x RAID - PCIe 3.0 x8
Controller Interface Type
SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name
Smart Array P440ar with 2GB FBWC
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 60, RAID 1 ADM, RAID 10 ADM
Graphics Processor
Matrox G200
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
HP 331i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Bays
1 (total) / 1 (free) x external 5.25" Slim Line ¦ 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
4 (total) / 4 (free) x PCIe 3.0 x8 - full-length, full-height (x4 mode) ¦ 3 (total) / 3 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 2.0 x8 - half-length, full-height (x4 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x8 mode) ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces
1 x VGA ¦ 1 x serial ¦ 4 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 3 x USB 3.0 (2 rear, 1 internal) ¦ 5 x USB 2.0 (2 front, 2 rear, 1 internal)
Included Accessories
8 x case fans, HPE Easy Install Rails
Compliant Standards
ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, ASHRAE, CNS 13438
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 120/230 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Citrix XenServer, Canonical Ubuntu
Sustainability Information
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
