EAN / GTIN:
0190017795133
Product Form Factor
Tower - 4.5U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Front Accessible Bays Qty
1
Localisation
Region: Europe
CPU
Intel Xeon Bronze 3508U
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, 125W TDP
Installed Size
L3 Cache - 22.5 MB
Cache Per Processor
22.5 MB
Installed Size
32 GB (installed) / 1 TB (max)
Technology
DDR5 SDRAM - ECC
Effective Memory Speed
2200 MHz
Rated Memory Speed
2800 MHz
Slots
16 (Total) / 15 (empty)
Features
Registered, HPE SmartMemory
Configuration Features
1 x 32 GB
Interface Type
SATA 6Gb/s
Features
Read Intensive, HPE Multi Vendor
Controller Interface Type
SATA-600 / NVMe
Storage Controller Name
Intel VROC SATA Software RAID
Video Interfaces
VGA, DisplayPort
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5720
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 6
Features
Wake on LAN (WoL), PXE support
Bays
1 (total) / 1 (free) x external 5.25" ¦ 8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
2 (total) / 2 (free) x PCIe 5.0 x16 ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode)
Interfaces
1 x DisplayPort 1.1a ¦ 1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO - Type A (1 in front) ¦ 1 x HPE iLO - RJ-45 (1 rear) ¦ 4 x USB 3.2 Gen 1 (1 front, 2 rear, 1 internal) ¦ 1 x USB 2.0 (1 internal)
Included Accessories
2 x standard fans
Compliant Standards
AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, ACPI 6.4, SMBIOS 3.4, UEFI 2.7, Active Directory v1.0, UEFI Class 3, APML, MCTP
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 100-120/200-240 V
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Sustainability Information
EPEAT Compliant
EPEAT Bronze
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
