Recommended Use
Small business, corporate business
Product Form Factor
Blade
CPU Upgradability
Upgradable
Installed Size
L3 Cache - 20 MB
Cache Per Processor
20 MB
Installed Size
32 GB (installed) / 512 GB (max)
Effective Memory Speed
1600 MHz
Rated Memory Speed
1600 MHz
Memory Specification Compliance
PC3-12800
Slots
16 (Total) / 12 (empty)
Features
Registered, quad channel memory architecture, HP SmartMemory
Configuration Features
4 x 8 GB
RAM Supported
PC3-12800 - 512 GB registered ¦ PC3-10600 - 128 GB unbuffered - Advanced ECC
Type
1 x SAS-2 - integrated - PCIe x4
Controller Interface Type
SATA 3Gb/s / SAS 6Gb/s
Storage Controller Name
Smart Array P220i with 512MB FBWC
RAID Level
RAID 0, RAID 1
Graphics Processor
Matrox G200
Interface (Bus) Type
PCI Express 2.0 x8
Ethernet Ports
2 x 10 Gigabit Ethernet
Data Link Protocol
Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Protocol
SNMP, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL)
Compliant Standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ap
Bays
2 (total) / 2 (free) x hot-swap 2.5" SFF
Slots
2 (total) / 1 (free) x CPU ¦ 16 (total) / 12 (free) x DIMM 240-pin ¦ 2 expansion slot ¦ 1 (total) / 1 (free) x SD card
Interfaces
1 x HPE iLO ¦ 2 x LAN (10Gigabit Ethernet)
Features
Administrator password, system password, power-on password, serial port I/O control
Compliant Standards
ACPI 2.0b, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, IEC 60950-1, EN 60950-1, BSMI CNS 13438, FCC CFR47 Part 15 B
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Red Hat Enterprise Linux, Microsoft Windows Server 2008, Oracle Solaris
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
