EAN / GTIN:
4948382859068
Recommended Use
Small business, corporate business
Product Form Factor
Blade
CPU Upgradability
Upgradable
Installed Size
L3 Cache - 20 MB
Cache Per Processor
20 MB
Installed Size
32 GB (installed) / 256 GB (max)
Technology
DDR3 SDRAM - Advanced ECC
Effective Memory Speed
1600 MHz
Rated Memory Speed
1600 MHz
Memory Specification Compliance
PC3-12800
Slots
16 (Total) / 12 (empty)
Features
Registered, quad channel memory architecture, HP SmartMemory
Configuration Features
4 x 8 GB
RAM Supported
PC3-12800 - 256 GB registered - Advanced ECC ¦ PC3-12800 - 128 GB unbuffered - Advanced ECC ¦ PC3-10600 - 512 GB - low voltage - Load-Reduced - Advanced ECC
Type
1 x SAS-2 - integrated - PCIe x4
Controller Interface Type
SAS 6Gb/s
Storage Controller Name
Smart Array P220i with 512MB FBWC
RAID Level
RAID 0, RAID 1
Graphics Processor
Matrox G200
Interface (Bus) Type
FlexibleLOM
Ethernet Ports
2 x 10 Gigabit Ethernet
Ethernet Controller
HP 554FLB
Data Link Protocol
Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Protocol
SNMP, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL)
Compliant Standards
IEEE 802.1Q, IEEE 802.1p, IEEE 802.3x, IEEE 802.3ad (LACP), IEEE 802.3ae, IEEE 802.3ap, IEEE 802.1Qau
Bays
2 (total) / 2 (free) x hot-swap 2.5" SFF
Slots
2 (total) / 1 (free) x CPU ¦ 16 (total) / 12 (free) x DIMM 240-pin ¦ 2 expansion slot (x16 mode) ¦ 1 (total) / 0 (free) x FlexibleLOM ¦ 1 (total) / 1 (free) x microSDHC Card (internal)
Interfaces
1 x HPE iLO ¦ 2 x LAN (10Gigabit Ethernet) ¦ 1 x USB 2.0 (1 internal)
Features
Administrator password, power-on password, USB port control, quick lock
Compliant Standards
ACPI 2.0, AES
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris, Citrix XenServer
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
