Product Form Factor
Rack-mountable - 1U
Built-in Devices
Led panel, 3 x fans
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: Germany, Switzerland, Austria, France, United Kingdom, Scotland, Ireland
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, Hyper-Threading Technology, Intel Turbo Boost Max 3.0, 12 Threads, 65W TDP
Installed Size
L3 Cache - 18 MB
Cache Per Processor
18 MB
Installed Size
32 GB (installed) / 128 GB (max)
Effective Memory Speed
4400 MT/s
Rated Memory Speed
4400 MT/s
Slots
4 (Total) / 3 (empty)
Features
HPE Standard Memory, unbuffered
Configuration Features
1 x 32 GB
Controller Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name
Intel RSTe
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
Graphics Processor
Matrox G200
Video Interfaces
DisplayPort, VGA
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5720
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
IPMI 2.0, SNMP 3
Features
ACPI support, PXE support, Wake on LAN (WoL)
Slots
1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x16 mode) ¦ 1 (total) / 0 (free) x Open Compute Project mezzanine (OCP) 3.0
Interfaces
1 x HPE iLO - Type A (1 in front) (service port) ¦ 5 x USB 3.2 Gen 1x1 - Type A (1 front, 4 rear) ¦ 2 x USB 3.2 Gen 2x2 (2 internal) ¦ 1 x DisplayPort ¦ 1 x VGA ¦ 4 x LAN (Gigabit Ethernet) - RJ-45
Included Accessories
3 performance single rotor non-hot plug and non-redundant fans
Compliant Standards
ACPI 6.3, PCIe 5.0, SMBIOS 3.2, UEFI 2.9, UEFI Class 3, Redfish API, AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Active Directory v1.0, EU Lot 9, FIPS 140-2, PCI DSS, IPv6 Ready, WEEE 2002/95/EC, DMTF
Manufacturer Selling Program
HPE Smart Choice
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 100-120/200-240 V
Operating System / Software
OS Provided
No operating system
OS Certified
Microsoft Windows Server 2019, Microsoft Windows Server 2022, VMware ESXi 8.0 update 2
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Sustainability Information
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
