EAN / GTIN:
0190017795126
Product Form Factor
Tower - 4U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: Europe
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, 65W TDP
Installed Size
L3 Cache - 18 MB
Cache Per Processor
18 MB
Installed Size
32 GB (installed) / 128 GB (max)
Technology
DDR5 SDRAM - ECC
Rated Memory Speed
2400 MHz
Slots
4 (Total) / 3 (empty)
Features
Unbuffered, HPE Standard Memory
Configuration Features
1 x 32 GB
Interface Type
SATA 6Gb/s
Features
Read Intensive, HPE Multi Vendor
Controller Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name
HPE MR216i-p Gen11 SPDM
RAID Level
RAID 0, RAID 1, RAID 10
Video Interfaces
VGA, DisplayPort
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5719
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 6
Features
Wake on LAN (WoL), PXE support
Bays
8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x16 mode, processor) ¦ 1 (total) / 1 (free) x PCIe 4.0 x8 - full-length, full-height (x4 mode, processor) ¦ 2 (total) / 1 (free) x PCIe 4.0 x8 - half-length, full-height (x4 mode, PCH) ¦ 1 (total) / 1 (free) x M.2 Card
Interfaces
1 x DisplayPort ¦ 1 x VGA ¦ 3 x LAN (Gigabit Ethernet) - RJ-45 (3 rear) ¦ 1 x HPE iLO - Type A (1 front) (service port) ¦ 5 x USB 3.2 Gen 1 (1 front, 4 rear) ¦ 1 x LAN (Gigabit Ethernet) / HPE iLO - RJ-45 (1 rear)
Included Accessories
Non-hot plug non-redundant system fan
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock eye
Security Slot Type
Kensington security slot
Compliant Standards
AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, ACPI 6.3, Active Directory v1.0, UEFI 2.9, EU Lot 9
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Sustainability Information
EPEAT Compliant
EPEAT Bronze
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts - 3 years - on-site - response time: next business day ¦ Limited warranty - parts and labour - 1 year - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
