HPE ProLiant DL320 Gen11 - rack-mountable Xeon Sil

Images Manuals

Images for illustrative purposes

HPE ProLiant DL320 Gen11

Name: HPE ProLiant DL320 Gen11
Brand: HPE
SKU: MMECN37491
Price: 9919.75 EUR
Availability: InStock

View all HPE Servers - Visit the HPE Store (P80510-425) - (MMECN37491)

Model: HPE ProLiant

ProLiant DL320 Gen11 - rack-mountable Xeon Silver 4510 2.4 GHz - 64 GB - SSD 2 x 480 GB

Advanced performance
Robust storage options
High-speed memory
Efficient power management
Comprehensive connectivity

FREE Delivery on orders over €250

SPO - THIS IS A SPECIAL ORDER ITEM AND CANNOT BE RETURNED AS UNWANTED OR CANCELLED. **Note: PLEASE CHECK, MONITOR NOT INCLUDED IN MOST PCs.

2 Available to Ship
Order within 5Hrs 42Mins for: FREE Delivery (8 Jun or 9 Jun)

RRP ~~€11459.06~~

€9919.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Do you need to efficiently expand or refresh your IT infrastructure to propel the business? Adaptable to diverse workloads and environments, the compact 1U 1P HPE ProLiant DL320 Gen11 delivers enhanced performance with the right balance of expandability and density. Designed for supreme versatility and resiliency, the HPE ProLiant DL320 Gen11 is ideal for IT infrastructure, either physical, virtual, or containerized.

The HPE ProLiant DL320 Gen11 supports the Intel Xeon, plus 4800 MT/s HPE DDR5 Smart Memory. Introducing PCIe Gen5 and Intel Software Guard Extensions (SGX) support on the single socket segment, the HPE ProLiant DL320 Gen11 delivers premium compute, memory, I/O, and security capabilities for customers focused on performance at 1P economics. DL320 Gen11 is an excellent choice for daily business and workloads in Data Management, Virtualization, Content Delivery Network (CDN), Intelligent Video Analytics (IVA), General Compute, Data Collection, Software Defined Storage, Software Defined Compute, Cold Storage, Compute Storage, Edge AI, and Virtual Desktop Infrastructure (VDI).

Specification Summary

Product Description

HPE ProLiant DL320 Gen11 - rack-mountable Xeon Silver 4510 2.4 GHz - 64 GB - SSD 2 x 480 GB

Type

Server - rack-mountable

Height (Rack Units)

Localisation

Region: Europe

Server Scalability

2-way

Processor

1 x Intel Xeon Silver 4510 / 2.4 GHz (up to 4.1 GHz, (12-core)

Cache Memory

30 MB L3 Cache

Cache Per Processor

30 MB

RAM

64 GB (installed) / 2.04 TB (max) - DDR5 SDRAM - Advanced ECC

Storage Controller

RAID (Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)) - OCP (HPE MR408i-o Gen11 SPDM)

Server Storage Bays

Hot-swap 2.5"

Hard Drive

2 x SSD 480 GB - SATA 6Gb/s

Optical Storage

No optical drive

Video Memory

16 MB

Networking

1GbE

Power

AC 120/230 V

Power Redundancy

Yes

OS Provided

No operating system

Software Included

HPE iLO Advanced, HPE OneView Standard (free download), HPE iLO Standard with Intelligent Provisioning

Dimensions (WxDxH)

43.46 cm x 60.51 cm x 4.28 cm

Weight

12 kg

Manufacturer Selling Program

HPE Smart Choice

Environmental Standards

ENERGY STAR Qualified

Manufacturer Warranty

Limited warranty - parts and labour - 3 years - on-site

Specifications

EAN / GTIN:

0190017788197

General

Type

Server

Product Form Factor

Rack-mountable - 1U

Built-in Devices

Led panel

Embedded Security

Trusted Platform Module (TPM 2.0) Security Chip

Server Scalability

2-way

Hot-Swap Bays Qty

Localisation

Region: Europe

Processor / Chipset

CPU

Intel Xeon Silver 4510

Clock Speed

2.4 GHz

Max Turbo Speed

4.1 GHz

Number of Cores

12-core

CPU Qty

Max CPU Qty

CPU Upgradability

Upgradable

Chipset Type

Intel C741

Cache Memory

Installed Size

L3 Cache - 30 MB

Cache Per Processor

30 MB

RAM

Installed Size

64 GB (installed) / 2.04 TB (max)

Technology

DDR5 SDRAM - Advanced ECC

Effective Memory Speed

2800 MHz

Rated Memory Speed

2800 MHz

Form Factor

DIMM 288-pin

Slots

16 (Total) / 14 (empty)

Features

Registered, HPE SmartMemory, slots 9 - 16 are available in two-processor configuration only

Configuration Features

2 x 32 GB

Hard Drive

Type

SSD

Capacity

2 x 480 GB

Interface Type

SATA 6Gb/s

Features

Read Intensive, basic carrier, HPE Multi Vendor

Storage Controller

Type

1 x RAID - OCP

Controller Interface Type

Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)

Storage Controller Name

HPE MR408i-o Gen11 SPDM

Channel Qty

RAID Level

RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60

Buffer Size

4 GB

Optical Storage

Type

No optical drive

Monitor

Monitor Type

None.

Graphics Controller

Video Memory

16 MB

Video Interfaces

VGA

Networking

Ethernet Ports

2 x Gigabit Ethernet

Ethernet Controller

Broadcom BCM5720

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Remote Management Protocol

IPMI 2.0, SNMP 3

Remote Management Controller

Integrated Lights-Out 6

Features

ACPI support, PXE support, Wake on LAN (WoL)

Expansion / Connectivity

Bays

8 (total) / 6 (free) x hot-swap 2.5" SFF

Slots

2 (total) / 2 (free) x PCIe 5.0 x16 - full-length, full-height (x16 mode) ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0

Interfaces

1 x HPE iLO (1 in front) (service port) ¦ 3 x USB 3.2 Gen 1 (1 front, 2 rear) ¦ 1 x VGA (1 rear) ¦ 2 x LAN (Gigabit Ethernet) (2 rear)

Miscellaneous

Included Accessories

7 x standard fans

Compliant Standards

ACPI 6.3, PCIe 5.0, SMBIOS 3.2, Redfish API, AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, DMTF, Active Directory v1.0, PCI DSS, FIPS 140-2, IPv6 Ready, UEFI 2.7

Manufacturer Selling Program

HPE Smart Choice

Power

Device Type

Power supply - hot-plug

Power Redundancy

Yes

Power Redundancy Scheme

1+1

Installed Qty

Max Supported Qty

Voltage Required

AC 120/230 V

Power Provided

1000 watt

80 PLUS Certification

80 PLUS Titanium

Operating System / Software

OS Provided

No operating system

OS Certified

VMware ESX, Windows, Linux

Software

HPE iLO Advanced, HPE OneView Standard (free download), HPE iLO Standard with Intelligent Provisioning

Sustainability Information

ENERGY STAR Certified

Yes

ENERGY STAR Version

4.0

Manufacturer Warranty

Service & Support

Limited warranty - parts and labour - 3 years - on-site

Dimensions & Weight

Width

43.46 cm

Depth

60.51 cm

Height

4.28 cm

Weight

12 kg

Environmental Parameters

Min Operating Temperature

10 °C

Max Operating Temperature

35 °C

Humidity Range Operating

8 - 90% RH (non-condensing)
