EAN / GTIN:
0190017810935
Product Form Factor
Tower - 4.5U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Front Accessible Bays Qty
1
Localisation
Region: Europe
CPU
Intel Xeon Gold 5416S
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2
Installed Size
L3 Cache - 30 MB
Cache Per Processor
30 MB
Installed Size
64 GB (installed) / 1 TB (max)
Technology
DDR5 SDRAM - Advanced ECC
Effective Memory Speed
4400 MT/s
Rated Memory Speed
4800 MT/s
Slots
16 (Total) / 14 (empty)
Features
Registered, HPE SmartMemory
Configuration Features
2 x 32 GB
Controller Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name
HPE MR408i-o Gen11 SPDM
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Bays
1 (total) / 1 (free) x external 5.25" ¦ 8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
2 (total) / 2 (free) x PCIe 5.0 x16 ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode)
Interfaces
1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO - RJ-45 (1 rear) ¦ 3 x USB 3.0 (1 front, 2 rear) ¦ 1 x HPE iLO - Type A (1 in front)
Included Accessories
2 x standard fans
Compliant Standards
AES, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, Redfish API, FIPS 140-3, ErP Lot 9, IPv4, ACPI 6.4, PCIe 5.0, SMBIOS 3.4, UEFI 2.7, DMTF, Active Directory v1.0, UEFI Class 3, APML, MCTP
Manufacturer Selling Program
HPE Smart Choice
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 100-120/200-240 V
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
No operating system
Software
HPE iLO Advanced, HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download), HPE Compute Ops Management (subscription included)
Sustainability Information
EPEAT Compliant
EPEAT Bronze
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
