Platform Technology
Intel vPro Platform
Type
Point of sale terminal
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
CPU
Intel Core i5 (8th Gen) 8500
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, Intel Smart Cache
Installed Size
L3 Cache - 9 MB
Installed Size
8 GB (installed) / 64 GB (max)
Technology
DDR4 SDRAM - non-ECC
Effective Memory Speed
2666 MHz
Rated Memory Speed
2666 MHz
Memory Specification Compliance
PC4-21333
Slots
4 (Total) / 3 (empty)
Configuration Features
1 x 8 GB
Interface Type
SATA 6Gb/s
Controller Interface Type
SATA-600 / NVMe
Graphics Processor
Intel UHD Graphics 630 Dynamic Video Memory Technology
Video Interfaces
DisplayPort
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Ethernet Controller
Intel I219-LM
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), ACPI support, PXE 2.1 support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.3az
Bays
1 (total) / 1 (free) x external 5.25" ¦ 2 (total) / 1 (free) x internal 3.5"
Slots
2 (total) / 2 (free) x PCIe x1 - full-height ¦ 1 (total) / 1 (free) x PCIe x16 - half-height (x16 mode) ¦ 1 (total) / 1 (free) x PCIe x16 - half-height (x4 mode) ¦ 2 (total) / 2 (free) x M.2 Card
Interfaces
5 x USB 3.1 Gen 1 (2 front, 3 rear) (one of them is charging) ¦ 1 x audio line-in ¦ 1 x PS/2 keyboard / mouse ¦ 1 x DisplayPort 2.0 ¦ 2 x USB 2.0 ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x HDMI ¦ 3 x PoweredUSB (12 V) ¦ 2 x serial (powered) ¦ 1 x PoweredUSB (24 V)
Theft/Intrusion Protection
Security lock slot (cable lock sold separately)
Security Slot Type
Kensington security slot
Compliant Standards
IEC 60601-1-2, RoHS, WEEE, CP65, low halogen, IEEE 1680
Voltage Required
AC 90-264 V (50/60 Hz)
Efficiency
87% at 20% Load, 90% at 50% Load, 87% at 100% Load
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 10 IoT Enterprise Retail
Software
HP Recovery Manager, HP Support Assistant, HP ePrint, HP Hotkey Support, HP Secure Erase, HP Client Catalog, HP BIOS Config Utility, HP JumpStart, HP Noise Cancellation, HP System Software Manager, HP JetAdvantage, HP Wireless Wakeup, HP BIOSphere Gen4, HP Manageability & Integration Kit Gen2, HP Client Security Suite Gen4, HP Driver Packs (free download)
Dimensions & Weight (Shipping)
Min Operating Temperature
10 °C
Max Operating Temperature
40 °C
Humidity Range Operating
20 - 85% (non-condensing)
