EAN / GTIN:
0190017827230
Product Form Factor
Rack-mountable - 2U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: Europe
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, Hyper-Threading Technology, 24 Threads, 150W TDP
Installed Size
L3 Cache - 48 MB
Cache Per Processor
48 MB
Installed Size
64 GB (installed) / 4 TB (max)
Slots
16 (Total) / 15 (empty)
Features
HPE SmartMemory, registered
Configuration Features
1 x 64 GB
Controller Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name
HPE MR408i-o Gen11 SPDM
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
Remote Management Controller
Integrated Lights-Out 7
Bays
8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
3 (total) / 3 (free) x PCIe 5.0 x16 ¦ 1 (total) / 0 (free) x Open Compute Project mezzanine (OCP) 3.0 (slot A)
Interfaces
1 x HPE iLO - Type C (1 in front) (service port) ¦ 1 x management (Gigabit Ethernet) - RJ-45 (1 front) (HPE iLO Service Port) ¦ 4 x USB 3.2 Gen 1 - Type A (1 front, 2 rear, 1 internal) ¦ 1 x VGA (1 rear)
Compliant Standards
ACPI 6.4, Energy Star, SMBIOS 3.4, Redfish API, AES, Triple DES, TLS v1.2, Active Directory v1.0, ASHRAE Class A3, ASHRAE Class A4, ErP Lot 9
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
80 PLUS Certification
80 PLUS Titanium
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
