Product Form Factor
Rack-mountable - 4U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: Germany, Switzerland, Austria, France, United Kingdom, Scotland, Ireland
Number of Cores
Quad-Core
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, Hyper-Threading Technology, Intel Smart Cache, 55W TDP
Installed Size
L3 Cache - 12 MB
Cache Per Processor
12 MB
Installed Size
32 GB (installed) / 128 GB (max)
Effective Memory Speed
4400 MT/s
Rated Memory Speed
4800 MT/s
Slots
4 (Total) / 3 (empty)
Features
HPE Standard Memory, unbuffered
Configuration Features
1 x 32 GB
Interface Type
SATA 6Gb/s
Features
HPE Multi Vendor, Read Intensive
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
Intel VROC SATA Software RAID
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Graphics Processor
Matrox G200
Video Interfaces
DisplayPort, VGA
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5719
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
IPMI 2.0, SNMP 3
Features
ACPI support, PXE support, Wake on LAN (WoL)
Bays
4 (total) / 2 (free) x hot-swap 2.5" SFF ¦ 1 (total) / 1 (free) x external
Slots
1 (total) / 1 (free) x PCIe 5.0 x16 - half-length, full-height (x16 mode) ¦ 1 (total) / 1 (free) x Open Compute Project mezzanine (OCP) 3.0
Interfaces
1 x HPE iLO - Type A (1 in front) (service port) ¦ 5 x USB 3.2 Gen 1x1 - Type A (1 front, 4 rear) ¦ 2 x USB 3.2 Gen 2x2 (2 internal) ¦ 1 x DisplayPort ¦ 1 x VGA ¦ 4 x LAN (Gigabit Ethernet) - RJ-45
Included Accessories
3 high performance non-hot plug and non-redundant fans, HPE Easy Install Rail 12 Kit
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock eye
Security Slot Type
Kensington security slot
Compliant Standards
ACPI 6.3, UEFI 2.9, Redfish API, AES, Triple DES, TLS v1.2, Active Directory v1.0, ASHRAE Class A4, ASHRAE Class A3
Manufacturer Selling Program
HPE Smart Choice
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 100-120/200-240 V
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Provided
No operating system
OS Certified
Microsoft Windows Server 2019, Microsoft Windows Server 2022, VMware ESXi 8.0 update 2
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Sustainability Information
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
