Elo I-Series 3 - all-in-one Core i5 i5-1245UL 1.6

Images Manuals

Images for illustrative purposes

Elo I-Series 3

Name: Elo I-Series 3
Brand: ELO TOUCHSYSTEMS
SKU: MMECP27455
Price: 3349.75 EUR
Availability: OutOfStock

View all ELO TOUCHSYSTEMS All Desktop PCs - Visit the ELO TOUCHSYSTEMS Store (E425976) - (MMECP27455)

Model: Elo I-Series

Elo I-Series 3 - all-in-one Core i5 i5-1245UL 1.6 GHz - 8 GB - SSD 256 GB - LED 15.6"

Advanced connectivity
High-performance processing
Innovative touch technology
Secure and reliable
Versatile design

FREE Delivery on orders over €250

**Note: PLEASE CHECK, MONITOR NOT INCLUDED IN MOST PCs.

0 Available to Ship
Restock 05-Jun-2026 Estimated, Out of Stock Prices are Estimated.

€3349.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The Elo I-Series 3 stands out as a comprehensive solution for businesses looking for a high-performance, secure, and interactive all-in-one computer. It is powered by a 10-core Intel Core i5 processor, ensuring that it can handle demanding applications with ease. The inclusion of TouchPro Pro Projected Capacitive (PCAP) technology offers a responsive 10-point multi-touch experience, making it suitable for interactive kiosks, point-of-sale systems, and more.

With its robust connectivity options, including LAN (Gigabit Ethernet), USB 3.0, and DisplayPort/USB-C 3.0, it seamlessly integrates into existing business environments, enhancing operational efficiency. The device is also designed with security in mind, featuring a Trusted Platform Module (TPM 2.0) security chip and ENERGY STAR 8.0 certification, ensuring data protection and energy efficiency. Its all-in-one form factor, complemented by VESA mount compatibility and a Kensington security slot, offers versatile installation options and secure placement in various business settings.

Specification Summary

Product Description

Elo I-Series 3 - all-in-one Core i5 i5-1245UL 1.6 GHz - 8 GB - SSD 256 GB - LED 15.6"

Type

Personal computer - all-in-one

Processor

Intel Core i5 (12th Gen) i5-1245UL / 1.6 GHz (up to 4.4 GHz, (10-core)

Processor Main Features

Intel Turbo Boost Technology 2, 12 Threads, Intel Smart Cache

Cache Memory

12 MB

Cache Per Processor

12 MB

RAM

8 GB (installed) / 64 GB (max) - DDR5 SDRAM

Hard Drive

SSD 256 GB - PCI Express - M.2 - NVM Express (NVMe)

Optical Storage

No optical drive

Monitor

15.6" - LED - 1024 x 768 (XGA) @ 60 Hz - 4:3 - touchscreen

Graphics Controller

Intel Iris Xe Graphics

Audio Output

Stereo

Networking

1GbE, 802.11a, Wi-Fi 5, Wi-Fi 6, 802.11b/g/n, Bluetooth 5.3

Power

(50/60 Hz)

OS Provided

Windows 11 IoT Enterprise 2024 LTSC (Windows 10 IoT Enterprise available through downgrade rights from Windows 11 IoT Enterprise) + Windows 10 IoT Enterprise Licence

Colour

Black

Dimensions (WxDxH)

38.41 cm x 3.72 cm x 24.77 cm

Weight

3.6 kg

Manufacturer Warranty

Limited warranty - 3 years

Specifications

EAN / GTIN:

0843173163680

General

Type

Personal computer

Product Form Factor

All-in-one

Built-in Devices

Dual 2 W speakers

Embedded Security

Trusted Platform Module (TPM 2.0) Security Chip

Colour

Black

Processor / Chipset

CPU

Intel Core i5 (12th Gen) i5-1245UL

Clock Speed

1.6 GHz

Max Turbo Speed

4.4 GHz (P-core) / 2.5 GHz (E-core)

Number of Cores

10-core

CPU Qty

Max CPU Qty

Processor Main Features

Intel Turbo Boost Technology 2, 12 Threads, Intel Smart Cache

Cache Memory

Installed Size

12 MB

Cache Per Processor

12 MB

RAM

Installed Size

8 GB (installed) / 64 GB (max)

Technology

DDR5 SDRAM

Effective Memory Speed

4800 MT/s

Rated Memory Speed

4800 MT/s

Form Factor

SO-DIMM 262-pin

Slots

2 (Total) / 1 (empty)

Configuration Features

1 x 8 GB

Hard Drive

Type

SSD - M.2

Capacity

1 x 256 GB

Interface Type

PCI Express

SSD Endurance

160 TB

Features

NVM Express (NVMe)

Optical Storage

Type

No optical drive

Monitor

Monitor Type

LED

Touchscreen

Yes (10-point multi-touch)

Diagonal Size

15.6"

Native Resolution

1024 x 768 (XGA)

V-Sync Rate at Max Res.

60 Hz

Widescreen Display

Image Aspect Ratio

4:3

Horizontal Viewing Angle

+80 / -80

Vertical Viewing Angle

+70 / -80

Response Time

23 ms

Image Brightness

340 cd/m²

Image Contrast Ratio

800:1

Monitor Features

TouchPro Pro Projected Capacitive (PCAP) technology, 50,000 backlight life, edge-to-edge glass, anti-glare, 262,000 colours

Graphics Controller

Graphics Processor

Intel Iris Xe Graphics

Audio Output

Sound Output Mode

Stereo

Speakers Included

2 x right / left channel

Networking

Wireless LAN Supported

Yes

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), IEEE 802.11b, IEEE 802.11g, IEEE 802.11n, Bluetooth 5.3

Features

Intel Active Management Technology (AMT)

Expansion / Connectivity

Interfaces

1 x headphones/microphone ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 ¦ 4 x USB 3.0 ¦ 4 x USB 2.0 - micro-USB ¦ 1 x PoweredUSB (24 V) ¦ 2 x PoweredUSB (12 V) ¦ 1 x serial - RJ-50 (powered) ¦ 1 x cash drawer (12V/24 V) ¦ 1 x DisplayPort/USB-C 3.0 (27 Watt charging)

Miscellaneous

Included Accessories

Power adapter, cable tie, CFD mounting screw, VESA mounting screw, VESA cover

Cables Included

RJ-50 to DB-9 cable

Theft/Intrusion Protection

Security lock slot (cable lock sold separately)

Security Slot Type

Kensington security slot

VESA Mounting Interface

75 x 75 mm, VESA

Compliant Standards

cUL, UL, IC, FCC, TUV, RCM, UKCA, CB, Argentina S-Mark, ANATEL, VCCI, MIC, CCC, SRRC, Mexico NOM, RoHS, CoC, R-NZ, IMDA, IP54

Power

Device Type

Power adapter

Voltage Required

AC 100/240 V (50/60 Hz)

Power Provided

180 Watt

Power Consumption Operational

50 Watt

Power Consumption Stand by

0.5 Watt

Power Consumption Sleep

5 Watt

Operating System / Software

OS Provided

Windows 11 IoT Enterprise 2024 LTSC (Windows 10 IoT Enterprise available through downgrade rights from Windows 11 IoT Enterprise) + Windows 10 IoT Enterprise Licence

Manufacturer Warranty

Service & Support

Limited warranty - 3 years

Dimensions & Weight

Width

38.41 cm

Depth

3.72 cm

Height

24.77 cm

Weight

3.6 kg
