EAN / GTIN:
0190017767680
Product Form Factor
Tower - 4.5U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Front Accessible Bays Qty
1
Localisation
Region: EMEA
CPU
Intel Xeon Silver 4510
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2
Installed Size
L3 Cache - 30 MB
Cache Per Processor
30 MB
Installed Size
32 GB (installed) / 1 TB (max)
Technology
DDR5 SDRAM - ECC
Effective Memory Speed
4400 MHz
Rated Memory Speed
5600 MHz
Slots
16 (Total) / 15 (empty)
Features
Registered, HPE SmartMemory
Configuration Features
1 x 32 GB
Controller Interface Type
SATA-600 / NVMe
Storage Controller Name
Intel VROC SATA Software RAID
Video Interfaces
VGA, DisplayPort
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5720
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 6
Features
Wake on LAN (WoL), PXE support
Bays
1 (total) / 1 (free) x external 5.25" ¦ 4 (total) / 2 (free) x hot-swap 3.5" LFF
Slots
2 (total) / 2 (free) x PCIe 5.0 x16 ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode)
Interfaces
1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO - RJ-45 (1 rear) ¦ 3 x USB 3.2 Gen 1 (1 front, 2 rear) ¦ 1 x HPE iLO - Type A (1 in front) ¦ 1 x DisplayPort 1.1a (1 front)
Included Accessories
2 non-hot plug standard fans
Compliant Standards
AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, ACPI 6.4, SMBIOS 3.4, UEFI 2.7, Active Directory v1.0, UEFI Class 3, APML, MCTP
Manufacturer Selling Program
HPE Smart Choice
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 100-120/200-240 V
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Sustainability Information
EPEAT Compliant
EPEAT Bronze
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
