Elo I-Series 4.0

Name: Elo I-Series 4.0
Brand: ELO TOUCHSYSTEMS
SKU: MMECC02007
Price: 1189.75 EUR
Availability: OutOfStock

View all ELO TOUCHSYSTEMS Other / POS Terminal - Visit the ELO TOUCHSYSTEMS Store (E391414) - (MMECC02007)

Model: Elo I-Series

Elo I-Series 4.0 - Value - all-in-one RK3399 - 4 GB - flash 32 GB - LED 21.5"

Versatile connectivity options
Robust all-in-one design
High-quality audio output

FREE Delivery on orders over €250

**Note: PLEASE CHECK, MONITOR NOT INCLUDED IN MOST PCs.

0 Available to Ship
Restock 05-Jun-2026 Estimated, Out of Stock Prices are Estimated.

€1189.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The I-Series has been used across the globe for everything from self-service, point-of-sale and price checkers to industrial controls and visitor management. Elo's I-Series delivers a powerful, commercial-grade interactive platform complete with a Full HD 10-touch display and enhanced CPU performance.

Features Summary

Versatile connectivity options
The device includes multiple interfaces such as Gigabit Ethernet, USB 2.0, USB 3.0, and USB-C, allowing for seamless integration with various peripherals and networks.
Robust all-in-one design
The all-in-one form factor combines performance and aesthetics, making it a space-saving solution ideal for any point of sale or customer interaction area.
High-quality audio output
Stereo sound output enhances the user experience, complemented by a microphone input for versatile audio functionality.

Specification Summary

Product Description

Elo I-Series 4.0 - Value - all-in-one RK3399 - 4 GB - flash 32 GB - LED 21.5"

Type

Point of sale terminal - all-in-one

Processor

1 x Rockchip RK3399

RAM

4 GB

Hard Drive

Flash 32 GB

Optical Storage

No optical drive

Card Reader

Yes

Monitor

21.5" - LED - 1920 x 1080 (Full HD) @ 60 Hz - 16:9 - touchscreen

Camera

Yes

Audio Output

Stereo

Networking

1GbE, 802.11a, Wi-Fi 5, 802.11b/g/n, Bluetooth 5.0

Power

(50/60 Hz)

OS Provided

Android 10

Software Included

Google Mobile Services

Colour

Black

Dimensions (WxDxH)

52.48 cm x 2.97 cm x 32.48 cm

Weight

4.3 kg

Manufacturer Warranty

Limited warranty - 2 years

Specifications

EAN / GTIN:

0843173128429

General

Type

Point of sale terminal

Product Form Factor

All-in-one

Colour

Black

Processor / Chipset

CPU

Rockchip RK3399

CPU Qty

Max CPU Qty

RAM

Installed Size

4 GB

Hard Drive

Type

Flash

Capacity

1 x 32 GB

Optical Storage

Type

No optical drive

Card Reader

Type

Card reader

Supported Flash Memory Cards

microSD

Monitor

Monitor Type

LED

Touchscreen

Yes (10-point multi-touch)

Diagonal Size

21.5"

Native Resolution

1920 x 1080 (Full HD)

V-Sync Rate at Max Res.

60 Hz

Widescreen Display

Yes

Image Aspect Ratio

16:9

Horizontal Viewing Angle

+85 / -85

Vertical Viewing Angle

+85 / -85

Response Time

5 ms

Image Brightness

215 cd/m²

Image Contrast Ratio

1000:1

Monitor Features

TouchPro Pro Projected Capacitive (PCAP) technology

Audio Output

Sound Output Mode

Stereo

Camera

Yes

Resolution (MP)

5 Megapixel

Resolution

1920 x 1080

Features

Autofocus

Audio Input

Type

Microphone

Networking

Wireless LAN Supported

Yes

Data Link Protocol

Ethernet, Gigabit Ethernet, Fast Ethernet, IEEE 802.11g, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n, IEEE 802.11b, Bluetooth 5.0

Compliant Standards

IEEE 802.11g, IEEE 802.11a, IEEE 802.11ac, IEEE 802.11n, IEEE 802.11b, Bluetooth 5.0

Expansion / Connectivity

Interfaces

1 x USB 3.0 (900 mA) ¦ 1 x USB-C ¦ 1 x GPIO ¦ 1 x LAN (Gigabit Ethernet) ¦ 4 x USB 2.0 - micro-USB (support for 1.2 A on one port and 500 mA for the remaining three ports)

Miscellaneous

Included Accessories

Power adapter, screw set

VESA Mounting Interface

75 mm, VESA, 100 mm

Compliant Standards

UL, cUL, FCC, IC, CB, VCCI, MIC, RCM

Power

Device Type

Power adapter

Voltage Required

AC 100-240 V (50/60 Hz)

Power Consumption Operational

15.7 Watt

Power Consumption Stand by

0.45 Watt

Power Consumption Sleep

2.7 Watt

Operating System / Software

OS Provided

Android 10

Software

Google Mobile Services

Manufacturer Warranty

Service & Support

Limited warranty - 2 years

Dimensions & Weight

Width

52.48 cm

Depth

2.97 cm

Height

32.48 cm

Weight

4.3 kg

Dimensions & Weight (Shipping)

Shipping Width

60 cm

Shipping Depth

16.8 cm

Shipping Height

40.6 cm

Shipping Weight

7.3 kg

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

20 - 80%
