Platform Technology
Intel vPro Platform
Product Form Factor
Tower
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Bundled with
HP Wolf Pro Security Edition (1 year)
CPU
Intel Core i7 (12th Gen) 12700
Clock Speed
2.1 GHz (P-core) / 1.6 GHz (E-core)
Max Turbo Speed
4.9 GHz (P-core) / 3.6 GHz (E-core)
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0, Intel vPro Platform Eligibility
Installed Size
L3 Cache - 25 MB
Cache Per Processor
25 MB
Installed Size
16 GB (installed) / 128 GB (max)
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Slots
4 (Total) / 3 (empty)
Configuration Features
1 x 16 GB
Interface Type
PCI Express
Features
NVM Express (NVMe)
Controller Interface Type
SATA 6Gb/s / PCIe 3.0 x4 (NVMe)
Graphics Processor
Intel UHD Graphics 770 Dynamic Video Memory Technology
Video Interfaces
HDMI, DisplayPort
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Interface (Bus) Type
PCI Express Mini Card (M.2)
Ethernet Controller
Intel I219-LM
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6E AX 211
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E)
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, dual stream (2x2)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3x, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED, IEEE 802.11h, IEEE 802.11k, IEEE 802.3az, IEEE 802.11r, IEEE 802.11v
Bays
2 (total) / 2 (free) x internal 3.5" ¦ 2 (total) / 2 (free) x external 5.25" Slim Line
Slots
1 (total) / 0 (free) x M.2 Card - 2230 (for WLAN) ¦ 2 (total) / 1 (free) x M.2 Card - 2280 (x4 mode) ¦ 2 (total) / 2 (free) x PCIe 3.0 x1 ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 (x4 mode) ¦ 1 (total) / 1 (free) x PCIe 4.0 x16
Interfaces
3 x USB 2.0 (3 rear) ¦ 3 x USB 3.2 Gen 1 ¦ 4 x USB 3.2 Gen 2 (4 in front) (one of them is fast-charging) ¦ 1 x USB-C 3.2 Gen 2x2 (1 in front) (charging) ¦ 2 x DisplayPort 1.4a ¦ 1 x headphones/microphone (1 in front) (CTIA headset support) ¦ 1 x audio line-out/line-in (1 rear) ¦ 1 x LAN (Gigabit Ethernet) ¦ 1 x HDMI ¦ 1 x USB 3.1 Gen 2
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Security Slot Type
Kensington security slot
Compliant Standards
ACPI, FCC Class B certified, ICES-003, CCC, FIPS 140-2 Level 2, RoHS, UL 60950-1, CSA C22.2 No. 60950-1-07, WEEE, KCC Class B, Common Criteria EAL4+, CECP, VCCI Class B, SEPA, low halogen, UL 62368-1, CAN/CSA-C22.2 No. 62368-1-14, IEEE 1680.1
Voltage Required
AC 90-264 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 11 Pro English
Software
HP Support Assistant, Windows Defender, Microsoft 365 (Trial), HP Secure Erase, HP Setup Integrated OOBE, HP PC Hardware Diagnostics, HP Notifications, HP Connection Optimizer, HP Sure Click, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP QuickDrop, HP WorkWell, HP BIOSphere Gen6, HP Wake on WLAN, myHP, Touchpoint Customiser for Commercial, HP Desktop Support Utilities, HP Tamper Lock, HP Noise Cancellation Software, HP Client Security Manager Gen7, HP SureRun Gen4, HP Sure Recover Gen4, HP Easy Clean, HP Sure Recover Gen5, HP Sure Sense Gen2, HP Sure Run Gen5, HP Sure Start Gen6, HP Sure Start Gen7
Sustainability Information
TCO Certified
TCO Certified Desktops 9
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 1 year - on-site
Dimensions & Weight (Shipping)
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
