EAN / GTIN:
0840292703636
Device Type
Wireless router
Bundled Services
3 years NetCloud Ruggedised IoT Essentials Plan
Connectivity Technology
Wired, wireless
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11ac, IEEE 802.11g, IEEE 802.11n, IEEE 802.11a, IEEE 802.11ax (Wi-Fi 6)
Frequency Band
2.4 GHz / 5 GHz
Performance
Maximum data rate (2.4 GHz): 574 Mbps ¦ Maximum data rate (5 GHz): 1.2 Gbps ¦ Stateful firewall throughput: 940 Mbps ¦ IPS throughput: 940 Mbps ¦ VPN throughput (IPSec): 100 Mbps ¦ LTE downlink bandwidth: 300 Mbps ¦ LTE uplink bandwidth: 150 Mbps
Capacity
Concurrent VPN tunnels: 20 ¦ Concurrent TCP sessions: 130000 ¦ Typical client count: 30
Encryption Algorithm
WPA-Personal, WPA2-Personal, WPA3-Personal, WPA2-Enterprise, WPA3-Enterprise
Features
Access Point operational mode, Wireless Client Mode, GPS/GLONASS/Galileo/BeiDou/QZSS support, Docker Support, dual core CPU, 3GPP Release 11, 2x2 MIMO technology, SMS remote control, DFS support, Ignition Sense
Compliant Standards
IEEE 802.11k, IEEE 802.11v, Wi-Fi CERTIFIED, GCF, IP64, UL, cUL, CB Scheme, EN 62368-1, E Mark, SAE J1455, IEC/EN 61373 Category 1 Class B, WEEE, RoHS, RoHS2, CP65, C1D2, MIL-STD 810G 514.6
Built-in Devices
GNSS receiver
Line Coding Format
64 QAM
Type
Wireless cellular modem
Mobile Communication Protocol
WCDMA, UMTS, HSPA+, FDD LTE, TDD LTE
Cellular Band
LTE B1, LTE B3, LTE B7, LTE B8, LTE B20, LTE B28, LTE B32, LTE B38, LTE B40, LTE B41, LTE B42, LTE B43, HSPA+ B1, HSPA+ B5, HSPA+ B8
Max Transfer Rate
300 Mbps
Internet of Things (IoT) Compatible
Yes
Communications Technology
LTE Cat 7, Bluetooth Low Energy (LE)
Interfaces
WAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ USB 2.0: 1 x 4 pin USB Type A ¦ Antenna: 2 x RP-SMA - Wi-Fi ¦ Antenna: 1 x RP-SMA - Bluetooth ¦ 1 x GPIO - 2 pin ¦ Antenna: 1 x SMA - GNSS aerial ¦ LAN: 1 x 10Base-T/100Base-TX/1000Base-T - RJ-45 ¦ Antenna: 2 x RP-SMA - LTE
Expansion Slots
2 (total) / 2 (free) x Nano-SIM
Aerial
External detachable
Power Device
External power adapter (not included)
Power Consumption Operational
14.5 Watt
Localisation
Australia, European Union, Malaysia, New Zealand, Singapore, South Africa, United Kingdom
Service & Support
Limited warranty - lifetime
Min Operating Temperature
-30 °C
Max Operating Temperature
70 °C
Humidity Range Operating
10 - 90%
Compatibility Information
Designed For
P/N: 170635-000, 170716-001, 170718-000, 170864-000, 170869-000, 170873-000, 170904-000
