Product Form Factor
Tower - 4U
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
CPU
Intel Core i7 (12th Gen) 12700
Clock Speed
2.1 GHz (P-core) / 1.6 GHz (E-core)
Max Turbo Speed
4.9 GHz (P-core) / 3.6 GHz (E-core)
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0
CPU Socket
LGA1700 Socket
Installed Size
L3 Cache - 25 MB
Cache Per Processor
25 MB
Installed Size
16 GB (installed) / 128 GB (max)
Technology
DDR5 SDRAM - non-ECC
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Slots
4 (Total) / 3 (empty)
Features
Unbuffered, dual channel memory architecture
Configuration Features
1 x 16 GB
Interface Type
PCI Express 4.0 x4
Features
NVM Express (NVMe), triple-level cell (TLC)
Controller Interface Type
SATA 6Gb/s / PCIe 4.0 x4 (NVMe)
RAID Level
RAID 0, RAID 1
Interface Type
PCIe 4.0 x16
Multi-GPU Configuration
1 single GPU card / integrated GPU
Graphics Processor
NVIDIA RTX A2000 / Intel UHD Graphics 770
Video Memory
12 GB GDDR6 SDRAM
Video Interfaces
DisplayPort
Compliant Standards
High Definition Audio
Interface (Bus) Type
M.2 Card
Ethernet Controller
Intel I219-LM
Wireless LAN Supported
Yes
Wireless NIC
Intel Wi-Fi 6E AX 211
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, Bluetooth 5.2, IEEE 802.11ax (Wi-Fi 6E)
Features
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, dual stream (2x2)
Bays
1 (total) / 1 (free) x external 5.25" ¦ 1 (total) / 1 (free) x external 5.25" Slim Line ¦ 2 (total) / 2 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x internal 2.5"
Slots
1 (total) / 0 (free) x PCIe 5.0 x16 ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 (x16 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 (x4 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x1 (x4 mode) ¦ 3 (total) / 2 (free) x M.2 Card - 2280 ¦ 1 (total) / 0 (free) x M.2 Card - 2230 (PCIe 3.0 x1 mode and Intel CNVi wireless module)
Interfaces
1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 6 x USB 3.2 Gen 2 (4 front, 2 rear) (one of them is charging) ¦ 1 x audio line-in ¦ 1 x audio line-out ¦ 6 x DisplayPort 1.4 ¦ 3 x USB 2.0 ¦ 1 x USB 3.2 Gen 1 ¦ 1 x LAN (Gigabit Ethernet)
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Security Slot Type
Kensington security slot
Compliant Standards
RoHS, FIPS 140-2, WEEE, Energy-Related Products (ErP) Lot 6, CECP, SEPA, low halogen
Voltage Required
AC 90-269 V (50/60 Hz)
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 11 Pro English
Software
HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOS Configuration Utility (free download), HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP System Software Manager (free download), HP Sure Click, HP Manageability Integration Kit, HP Sure Sense, HP Sure Admin, HP Client Security Manager Gen6, HP BIOSphere Gen6, HP ZCentral Remote Boost, HP Tamper Lock, HP Client Security Manager Gen7, HP Sure Recover Gen4, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0, HP Sure Sense Gen2, HP Sure Run Gen5, HP Sure Start Gen7
Sustainability Information
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 85% RH (non-condensing)
