Recommended Use
Small business, corporate business
Product Form Factor
Rack-mountable - 2U
Embedded Security
Trusted Platform Module (TPM 1.2) Security Chip
Localisation
Region: Worldwide (excluding China, Japan)
CPU Upgradability
Upgradable
Installed Size
L3 Cache - 15 MB
Cache Per Processor
15 MB
Installed Size
8 GB (installed) / 384 GB (max)
Effective Memory Speed
1600 MHz
Slots
24 (Total) / 23 (empty)
Features
Registered, HP SmartMemory
Configuration Features
1 x 8 GB
RAM Supported
PC4-17000 - 384 GB registered ¦ PC4-17000 - 768 GB Load-Reduced
Type
1 x RAID - integrated
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
HP Dynamic Smart Array B140i
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Graphics Processor
Matrox G200eH2
Interface (Bus) Type
PCI Express x2
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
HP 331i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Bays
8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
2 (total) / 1 (free) x CPU ¦ 24 (total) / 23 (free) x DIMM 288-pin ¦ 2 (total) / 2 (free) x PCIe 3.0 x16 - half-length, full-height (x8 mode) ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces
4 x LAN (Gigabit Ethernet) - RJ-45 ¦ 1 x HPE iLO - RJ-45 ¦ 1 x VGA ¦ 5 x USB 3.0 (1 front, 2 rear, 2 internal)
Included Accessories
HP Easy Install Rails
Features
Administrator password, power-on password, serial port I/O control, UEFI BIOS
Compliant Standards
ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, CNS 13438
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 120/230 V
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris, Citrix XenServer, Canonical Ubuntu
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
