Recommended Use
Small business, corporate business
Product Form Factor
Rack-mountable - 1U
Embedded Security
Trusted Platform Module (TPM 1.2) Security Chip
Front Accessible Bays Qty
1
Localisation
Region: Worldwide
CPU Upgradability
Upgradable
Processor Main Features
Intel Smart Cache
CPU Socket
FCLGA2011-v3 Socket
Installed Size
L3 Cache - 15 MB
Cache Per Processor
15 MB
Installed Size
8 GB (installed) / 768 GB (max)
Technology
DDR4 SDRAM - Advanced ECC
Effective Memory Speed
1600 MHz
Rated Memory Speed
2133 MHz
Memory Specification Compliance
PC4-17000
Slots
24 (Total) / 23 (empty)
Features
Registered, Online Spare Memory, quad channel memory architecture, HP SmartMemory
Configuration Features
1 x 8 GB
RAM Supported
3 TB Load-Reduced - Advanced ECC ¦ 768 GB registered - Advanced ECC
Type
1 x RAID - plug-in card - PCIe 3.0 x8
Controller Interface Type
SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name
HP H240ar Smart Host Bus Adapter
RAID Level
RAID 0, RAID 1, RAID 5
Graphics Processor
Matrox G200
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
HP 331i
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 4
Features
Wake on LAN (WoL), PXE support
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Bays
1 (total) / 1 (free) x external ¦ 8 (total) / 8 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 3.0 x16 - three-quarter-length, full-height ¦ 1 (total) / 0 (free) x PCIe 3.0 x8 - low-profile ¦ 1 (total) / 1 (free) x FlexibleLOM ¦ 1 (total) / 1 (free) x microSD Card (internal)
Interfaces
1 x VGA ¦ 4 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO ¦ 5 x USB 3.0 (1 front, 2 rear, 2 internal)
Included Accessories
HPE Easy Install Rails
Features
Administrator password, power-on password, keyboard password, serial port I/O control, quick lock, UEFI BIOS
Compliant Standards
ACPI 2.0b, FCC Class A certified, EN 61000-3-2, EN55022, ICES-003, EN 61000-3-3, EN55024, CISPR 22, FCC CFR47 Part 15, IEC 60950-1, EN 60950-1, WEEE, GB 9254, ASHRAE, CNS 13438
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 120/230 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Certified
SUSE Linux Enterprise Server, Microsoft Windows Server, Red Hat Enterprise Linux, Oracle Solaris, Citrix XenServer, Canonical Ubuntu
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
