Lenovo ThinkCentre M70s Gen 5 - SFF Core i7 i7-147

Images Manuals

Images for illustrative purposes

Lenovo ThinkCentre M70s Gen 5

Name: Lenovo ThinkCentre M70s Gen 5
Brand: LENOVO
SKU: ECE12266468
Price: 1404.89 EUR
Availability: OutOfStock

View all LENOVO All Desktop PCs - Visit the LENOVO Store (12U8009JUK) - (ECE12266468)

Model: Lenovo ThinkCentre

ThinkCentre M70s Gen 5 12U8 - SFF Core i7 i7-14700 / up to 5.4 GHz - RAM 16 GB - SSD 512 GB - TCG Opal Encryption - DVD-Writer - UHD Graphics 770 - Gigabit Ethernet - Win 11 Pro - monitor: none - keyboard: UK - black

Intelligent Performance With AI Enhancements
Enhanced Productivity
Unmatched Security
Multitasking Flexibility
Flexibilitet för multitasking

FREE Delivery on orders over €250

**Note: PLEASE CHECK, MONITOR NOT INCLUDED IN MOST PCs.

0 Available to Ship
Restock 29-Jun-2026 Estimated, Out of Stock Prices are Estimated.

€1404.89 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Fast, powerful small-form factor desktop PC

AI-accelerated features to enhance performance

Up to 14th Gen Intel Core processors with Intel vPro Enterprise

ThinkShield security solutions to protect your data and your business.

Specification Summary

Product Description

Lenovo ThinkCentre M70s Gen 5 - SFF Core i7 i7-14700 2.1 GHz - 16 GB - SSD 512 GB - UK

Type

Personal computer - SFF

Localisation

Language: English / region: United Kingdom

Processor

Intel Core i7 (14th Gen) i7-14700 / 2.1 GHz (up to 5.4 GHz, (20-core)

Cache Memory

33 MB

Cache Per Processor

33 MB

RAM

16 GB (installed) / 64 GB (max) - DDR5 SDRAM

Hard Drive

SSD 512 GB - PCI Express 4.0 x4 - M.2 2280 - TCG Opal Encryption

Optical Storage

DVD-Writer

Card Reader

3 in 1

Graphics Controller

Intel UHD Graphics 770 Shared Video Memory (UMA)

Networking

1GbE

Keyboard

Power

(50/60 Hz)

OS Provided

Windows 11 Pro

Colour

Black

Dimensions (WxDxH)

9.25 cm x 29.77 cm x 33.95 cm

Weight

5.3 kg

Environmental Standards

TCO Certified Desktops 9

Carbon Footprint

537 kg carbon emissions (EU)

Specifications

EAN / GTIN:

0199275017940

General

Type

Personal computer

Product Form Factor

SFF

Built-in Devices

Speaker

Embedded Security

Discrete Trusted Platform Module (TPM 2.0) Security Chip

Colour

Black

Localisation

Language: English / region: United Kingdom

Processor / Chipset

CPU

Intel Core i7 (14th Gen) i7-14700

Clock Speed

2.1 GHz (P-core) / 1.5 GHz (E-core)

Max Turbo Speed

5.4 GHz (P-core) / 4.2 GHz (E-core)

Number of Cores

20-core

CPU Qty

Max CPU Qty

Chipset Type

Intel Q670

Cache Memory

Installed Size

33 MB

Cache Per Processor

33 MB

RAM

Installed Size

16 GB (installed) / 64 GB (max)

Technology

DDR5 SDRAM

Effective Memory Speed

5600 MT/s

Rated Memory Speed

5600 MT/s

Form Factor

DIMM 288-pin

Slots

2 (Total) / 1 (empty)

Features

Unbuffered, dual channel memory architecture

Configuration Features

1 x 16 GB

Hard Drive

Type

SSD - M.2 2280

Capacity

1 x 512 GB

Manufacturer

Samsung

Interface Type

PCI Express 4.0 x4

Features

TCG Opal Encryption

Optical Storage

Type

DVD-Writer - SATA

Card Reader

Type

3 in 1 card reader

Supported Flash Memory Cards

SD Memory Card, SDHC Memory Card, SDXC Memory Card

Monitor

Monitor Type

None.

Graphics Controller

Graphics Processor

Intel UHD Graphics 770 Shared Video Memory (UMA)

Video Interfaces

HDMI, DisplayPort

Max Monitors Supported

Audio Output

Compliant Standards

High Definition Audio

Input Device

Type

Mouse, keyboard

Keyboard

Keyboard Name

Lenovo AI Keyboard

Interface

USB

Localization & Layout

Mouse

Mouse Name

Lenovo Calliope Mouse

Interface

USB

Networking

Ethernet Controller

Intel I219-LM

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Features

Wake on LAN (WoL)

Expansion / Connectivity

Bays

1 (total) / 1 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x 5.25" Slim Line

Slots

1 (total) / 1 (free) x M.2 Card (for WLAN) ¦ 1 (total) / 0 (free) x M.2 Card (for SSD) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 ¦ 1 (total) / 1 (free) x PCIe 3.0 x1

Interfaces

1 x USB-C 3.2 Gen 1 (1 front) (one of them is 15W charging) ¦ 4 x USB 3.2 Gen 1 (4 front) ¦ 1 x headphones/microphone (1 front) ¦ 1 x microphone (1 front) ¦ 4 x USB 2.0 (4 rear) ¦ 1 x HDMI (1 rear) (TMDS compatible) ¦ 1 x DisplayPort 1.4a (1 rear) ¦ 1 x LAN (1 rear)

Miscellaneous

Theft/Intrusion Protection

Security lock slot (cable lock sold separately), padlock loop, tool-less chassis access

Security Slot Type

Kensington security slot

Compliant Standards

RoHS, FIPS 140-2, GREENGUARD, Energy-Related Products (ErP) Lot 3, TCG Certified

Power

Device Type

Power supply

Voltage Required

AC 100-240 V (50/60 Hz)

Power Provided

260 Watt

Efficiency

90%

Operating System / Software

OS Provided

Windows 11 Pro English

Sustainability Information

TCO Certified

TCO Certified Desktops 9

Carbon Footprint

537 kg carbon emissions (EU)

Total CF/unit Standard Deviation (kg CO2e)

129

PAIA Version

1.4.0

Dimensions & Weight

Width

9.25 cm

Depth

29.77 cm

Height

33.95 cm

Weight

5.3 kg

Dimensions & Weight (Shipping)

Shipping Width

19.5 cm

Shipping Depth

39.5 cm

Shipping Height

53 cm

Environmental Parameters

Min Operating Temperature

5 °C

Max Operating Temperature

35 °C

Humidity Range Operating

20 - 80%
