EAN / GTIN:
5054444757995
Product Form Factor
Rack-mountable - 1U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: EMEA
Cache Per Processor
24 MB
Installed Size
32 GB (installed) / 128 GB (max)
Technology
DDR5 SDRAM - ECC
Effective Memory Speed
4400 MT/s
Rated Memory Speed
4400 MT/s
Slots
4 (Total) / 3 (empty)
Configuration Features
1 x 32 GB
Type
1 x RAID - PCIe 4.0 x8
Controller Interface Type
SATA 6Gb/s / SAS 12Gb/s
Storage Controller Name
ThinkSystem RAID 545-8i
RAID Level
RAID 0, RAID 1, RAID 10, JBOD
Graphics Processor
Matrox G200
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5720
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
XClarity Controller 2 (XCC2) Platinum
Features
PXE support, Teaming support
Bays
8 (total) / 8 (free) x hot-swap 2.5"
Slots
1 (total) / 1 (free) x PCIe 4.0 x8 - low-profile ¦ 1 (total) / 1 (free) x PCIe 4.0 x8 - half-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 (for internal storage controller) ¦ 2 (total) / 2 (free) x M.2 Card
Interfaces
1 x USB 2.0 (1 in front) ¦ 1 x USB 3.2 Gen 1 (1 in front) ¦ 2 x USB 3.2 Gen 2 ¦ 1 x serial ¦ 1 x VGA ¦ 1 x management - RJ-45 ¦ 2 x LAN (Gigabit Ethernet) - RJ-45
Included Accessories
Friction rail kit
Compliant Standards
GS, CCC, IEC 60950-1, FCC Part 15 A, GB 17625.1, CECP, VCCI Class A, GB 4943.1, INMETRO, NOM-019, EK1-ITB2000, KN35, AS/NZS CISPR 32 Class A, KN32 Class A, EN 62368-1, IEC 62368-1, EN 55032 Class A, CISPR 32 Class A, EN 55035, TP TC 004/2011, TP TC 020/2011, EN61000-3-11, EN61000-3-12, CELP, HJ 2507-2011, CNS 15663, Energy-Related Products (ErP) Lot 9, TP EAC 037/2016, AS/NZS 62368.1, UKCA, ANSI/UL 62368-1, ICES-003 issue 7 Class A, GB/T9254, CQC3135, CSA C22.2 No. 62368-1, CMIM, NRCS LOA, TUV-GS, IEC/EN 63000, (EU) 2019/424, UL2819, BIS 13252 (Part 1), UkrCEPRO, CNS 15936 Class A, CNS 15598-1
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 100-240 V (50/60 Hz)
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Provided
No operating system
Sustainability Information
EPEAT Compliant
EPEAT Bronze
ENERGY STAR Certified
Yes
Carbon Footprint
1586 kg carbon emissions
Total CF/unit Standard Deviation (kg CO2e)
788
Service & Support
Limited warranty - 3 years
Dimensions & Weight (Shipping)
