Product Form Factor
Tower - 4U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: Austria, France, Germany, Switzerland, United Kingdom, Ireland, Scotland
Number of Cores
Quad-Core
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology 2, 55W TDP
Installed Size
L3 Cache - 12 MB
Cache Per Processor
12 MB
Installed Size
32 GB (installed) / 128 GB (max)
Effective Memory Speed
4400 MT/s
Rated Memory Speed
4800 MT/s
Slots
4 (Total) / 3 (empty)
Features
Unbuffered, HPE Standard Memory
Configuration Features
1 x 32 GB
Interface Type
SATA 6Gb/s
Features
Business critical, HPE Multi Vendor
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
Intel VROC SATA Software RAID
RAID Level
RAID 0, RAID 1, RAID 5, RAID 10
Video Interfaces
VGA, DisplayPort
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5719
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 6
Features
Wake on LAN (WoL), PXE support
Bays
4 (total) / 2 (free) x internal 3.5" LFF
Slots
1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x16 mode, processor) ¦ 1 (total) / 1 (free) x PCIe 4.0 x8 - full-length, full-height (x4 mode, processor) ¦ 2 (total) / 2 (free) x PCIe 4.0 x8 - half-length, full-height (x4 mode, PCH) ¦ 1 (total) / 1 (free) x M.2 Card (PCIe 3.0 x2/NVMe)
Interfaces
1 x DisplayPort ¦ 1 x VGA ¦ 3 x LAN (Gigabit Ethernet) - RJ-45 (3 rear) ¦ 1 x HPE iLO - Type A (1 front) (service port) ¦ 5 x USB 3.2 Gen 1 (1 front, 4 rear) ¦ 1 x LAN (Gigabit Ethernet) / HPE iLO - RJ-45 (1 rear)
Included Accessories
Standard Fan
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock eye
Security Slot Type
Kensington security slot
Compliant Standards
AES, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, ACPI 6.3, Active Directory v1.0, UEFI 2.9
Voltage Required
AC 100-120/200-240 V
Operating System / Software
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Sustainability Information
EPEAT Compliant
EPEAT Bronze
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts - 3 years - response time: next business day ¦ Limited warranty - parts and labour - 1 year - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
