Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
CPU
Intel Core Ultra 5 (Series 2) 235
Clock Speed
3.4 GHz (P-core) / 2.9 GHz (E-core)
Max Turbo Speed
5 GHz (P-core) / 4.4 GHz (E-core)
CPU Upgradability
Upgradable
Processor Main Features
Intel Turbo Boost Technology
Neural Processor Unit (NPU)
Neural Processor Unit (NPU)
Intel AI Boost
NPU Performance Up To (TOPS)
13 TOPS
Total Processor Performance Up To (TOPS)
27 TOPS
AI Datatype Support on NPU
INT8
AI Software Frameworks Supported by NPU
DirectML, OpenVINO, WebNN, WindowsML, ONNX RT
Windows Studio Effects Support
Yes
Installed Size
L3 Cache - 24 MB
Cache Per Processor
24 MB
Installed Size
16 GB (installed) / 128 GB (max)
Effective Memory Speed
5600 MT/s
Rated Memory Speed
5600 MT/s
Slots
4 (Total) / 3 (empty)
Configuration Features
1 x 16 GB
Interface Type
PCI Express
Features
NVM Express (NVMe)
Controller Interface Type
SATA 6Gb/s / PCIe 4.0 x4 (NVMe)
Graphics Processor
Intel Graphics Dynamic Video Memory Technology - up to 6 TOPS
Video Interfaces
HDMI, DisplayPort
Max Sampling Rate
192 kHz
Compliant Standards
High Definition Audio
Interface (Bus) Type
PCI Express Mini Card (M.2)
Ethernet Controller
Intel I219-LM
Wireless LAN Supported
Yes
Wireless NIC
Intel WI-FI 7 BE200
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7)
Remote Management Protocol
SNMP 2
Features
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, dual stream (2x2)
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.11b, IEEE 802.11a, IEEE 802.3x, IEEE 802.11d, IEEE 802.11g, IEEE 802.1x, IEEE 802.11i, Wi-Fi CERTIFIED
Bays
1 (total) / 1 (free) x internal 3.5" ¦ 1 (total) / 0 (free) x external 5.25" Slim Line
Slots
1 (total) / 0 (free) x M.2 Card - 2230 (PCIe 3.0 x1 mode (for wireless module)) ¦ 3 (total) / 2 (free) x M.2 Card - 2280 (PCIe 4.0 x4 mode (for internal storage)) ¦ 1 (total) / 1 (free) x PCIe 4.0 x4 ¦ 1 (total) / 1 (free) x PCIe 4.0 x16
Interfaces
3 x USB 2.0 (3 rear) (two of them with wake functionality) ¦ 2 x USB 3.2 Gen 1 (2 rear) ¦ 4 x USB 3.2 Gen 2 (4 in front) ¦ 2 x USB-C 3.2 Gen 2x2 (2 front) (charging) ¦ 2 x DisplayPort 2.1 (2 rear) ¦ 1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 1 x audio line-out/line-in (1 rear) ¦ 1 x LAN (Gigabit Ethernet) - RJ-45 (1 rear) ¦ 1 x HDMI (1 rear)
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop, chassis intrusion sensor
Security Slot Type
Kensington security slot
Compliant Standards
ACPI, CCC, RoHS, WEEE, Common Criteria EAL4+, CECP, SEPA, low halogen
Manufacturer Selling Program
HP Smart Buy
Voltage Required
AC 100-240 V (50/60 Hz)
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 11 Pro English
Software
HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Secure Erase, HP BIOSphere, HP Client Catalogue (free download), HP Image Assistant (free download), HP Notifications, HP Connection Optimizer, HP Sure Click, HP Sure Run, HP Sure Recover, HP Privacy Settings, HP Cloud Recovery, HP Sure Sense, HP Sure Admin, HP Client Management Script Library (free download), myHP, Touchpoint Customiser for Commercial, HSA Fusion for Commercial, HSA Telemetry for Commercial, HP Desktop Support Utilities, HP BIOS Recovery, HP Easy Clean, HP Manageability Integration Kit (free download), HP Connect for Microsoft Endpoint Manager, HP Patch Assistant (free download), HP PC Hardware Diagnostics Windows, HP Easy Clean Keyboard Driver, HP Sure Start, HP Driver Packs (free download), HP UEFI BIOS Certification level 2.7B
Sustainability Information
EPEAT Compliant
EPEAT Gold
ENERGY STAR Certified
Yes
Dimensions & Weight (Shipping)
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 90% (non-condensing)
