EAN / GTIN:
4711387103463
Product Form Factor
Rack-mountable - 2U
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
CPU Upgradability
Upgradable
CPU Socket
LGA4677 Socket-E
Installed Size
0 GB (installed) / 12 TB (max)
Slots
32 (Total) / 32 (empty)
Features
Registered, 3DS registered, 8-channel memory architecture
Controller Interface Type
SATA 6Gb/s
Controller Interface Type
PCI Express (NVMe)
Graphics Processor
ASPEED AST2600
Ethernet Ports
2 x 10 Gigabit Ethernet
Ethernet Controller
2 x Intel X710-AT2
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, 2.5 Gigabit Ethernet, 5 Gigabit Ethernet, 100 Gigabit Ethernet
Bays
12 (total) / 12 (free) x hot-swap 2.5" / 3.5" shared
Slots
1 (total) / 1 (free) x Open Compute Project mezzanine (OCP) 3.0 ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 - low-profile ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height ¦ 6 (total) / 6 (free) x PCIe 5.0 x8 - full-length, full-height
Interfaces
1 x VGA ¦ 4 x USB 3.2 Gen 1 (2 front, 2 rear) ¦ 1 x management - RJ-45 ¦ 2 x 10 Gigabit Ethernet - RJ-45
Power Redundancy Scheme
1+1
80 PLUS Certification
80 PLUS Platinum
Operating System / Software
OS Provided
No operating system
Dimensions & Weight (Shipping)
Shipping Weight
25.855 kg
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
20 - 90% (non-condensing)
