Product Form Factor
Rack-mountable - 2U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
CPU
Intel Xeon Silver 4310
CPU Upgradability
Upgradable
Installed Size
L3 Cache - 18 MB
Cache Per Processor
18 MB
Installed Size
64 GB (installed) / 1.54 TB (max)
Effective Memory Speed
1600 MHz
Rated Memory Speed
1600 MHz
Slots
24 (Total) / 22 (empty)
Features
Registered, HPE SmartMemory, slots 13 - 24 are available in two-processor configuration only
Configuration Features
2 x 32 GB
RAM Supported
3 TB Load-Reduced ¦ 1.54 TB registered ¦ 192 GB Non-Volatile
Interface Type
SATA 6Gb/s
Features
Basic carrier, HPE Multi Vendor, Read Intensive
Controller Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name
HPE SR416i-a Gen10
Ethernet Ports
4 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5719
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Protocol
SNMP 3, IPMI 2.0, SMASH CLP
Remote Management Controller
Integrated Lights-Out 5
Features
Wake on LAN (WoL), PXE support
Bays
1 (total) / 1 (free) x external Universal Media Bay ¦ 8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x FlexibleLOM ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x8 - half-length, full-height
Interfaces
1 x HPE iLO - Type A (1 in front) ¦ 5 x USB 3.0 (1 front, 2 rear, 2 internal) ¦ 1 x HPE iLO - RJ-45 (1 rear) ¦ 4 x LAN (Gigabit Ethernet) - RJ-45 (4 rear) ¦ 1 x VGA (1 rear)
Included Accessories
6 standard fans
Compliant Standards
ACPI 6.1, PCIe 3.0, SMBIOS 3.1, Redfish API, AES, Triple DES, ASHRAE Class A4, ASHRAE Class A3, TLS v1.2, UEFI, ErP Lot 9, FIPS 140-2, WEEE 2002/95/EC, low halogen, Active Directory v1.0
Manufacturer Selling Program
HPE Smart Choice
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 100-240 V
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Provided
No operating system
OS Certified
Microsoft Windows Server, VMware ESXi
Software
HPE iLO Advanced, HPE OneView Standard (free download), HPE OneView Advanced, HPE Server UEFI
Sustainability Information
ENERGY STAR Certified
Yes
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
