Product Form Factor
Rack-mountable - 2U
Built-in Devices
Led panel
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Region: EMEA
CPU Upgradability
Upgradable
Installed Size
L3 Cache - 64 MB
Cache Per Processor
64 MB
Installed Size
64 GB (installed) / 6 TB (max)
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Slots
24 (Total) / 22 (empty)
Features
Registered, HPE SmartMemory, slots 13 - 24 are available in two-processor configuration only
Configuration Features
2 x 32 GB
Storage Controller Name
HPE MR408i-o Gen11 SPDM
Interface (Bus) Type
Open Compute Project mezzanine (OCP) 3.0
Ethernet Ports
2 x 10 Gigabit Ethernet
Ethernet Controller
Broadcom BCM57416
Data Link Protocol
Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Protocol
IPMI 2.0, SNMP 3
Remote Management Controller
Integrated Lights-Out 6
Features
Wake on LAN (WoL), PXE support
Bays
8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 5.0 x16 (x16 mode)
Interfaces
1 x HPE iLO (1 in front) (service port) ¦ 5 x USB 3.2 Gen 1 (1 front, 2 rear, 2 internal) ¦ 1 x VGA ¦ 2 x LAN (1/10 Gigabit Ethernet)
Included Accessories
6 x standard fans, HPE standard heatsink, HPE Easy Install Rail 2 Kit
Compliant Standards
AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1, SMBIOS 3.1, UEFI 2.7, Redfish API, APML 1.0, Active Directory v1.0
Manufacturer Selling Program
HPE Smart Choice
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 100-240 V (50/60 Hz)
80 PLUS Certification
80 PLUS Titanium
Sustainability Information
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight (Shipping)
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
