Product Form Factor
Rack-mountable - 1U
Built-in Devices
Led panel
Localisation
Region: EMEA
CPU Upgradability
Upgradable
Installed Size
L3 Cache - 64 MB
Cache Per Processor
64 MB
Installed Size
64 GB (installed) / 3 TB (max)
Technology
DDR5 SDRAM - Advanced ECC
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Slots
12 (Total) / 10 (empty)
Features
Registered, HPE SmartMemory, Online Spare Memory
Configuration Features
2 x 32 GB
Controller Interface Type
Serial ATA-600 / SAS 3.0 / PCI Express (NVMe)
Storage Controller Name
HPE MR408i-o Gen11 SPDM
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, RAID 50, RAID 60
Interface (Bus) Type
Open Compute Project mezzanine (OCP) 3.0
Ethernet Ports
2 x 10 Gigabit Ethernet
Ethernet Controller
Broadcom BCM57416
Data Link Protocol
Gigabit Ethernet, 10 Gigabit Ethernet
Remote Management Protocol
IPMI 2.0, SNMP 3
Remote Management Controller
Integrated Lights-Out 6
Features
PXE support, Wake on LAN (WoL)
Bays
8 (total) / 6 (free) x hot-swap 2.5" SFF
Slots
1 (total) / 1 (free) x PCIe 5.0 x16 - full-length, full-height (x16 mode)
Interfaces
1 x HPE iLO (1 in front) (service port) ¦ 1 x HPE iLO - RJ-45 ¦ 1 x VGA ¦ 2 x LAN (1/10 Gigabit Ethernet) ¦ 5 x USB 3.2 Gen 1 (1 front, 2 rear, 2 internal)
Included Accessories
7 x standard fans, HPE Easy Install Rail 2 Kit
Compliant Standards
AES, FIPS 140-2, Triple DES, IPv6 Ready, PCI DSS, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, WEEE 2002/95/EC, ACPI 6.1, SMBIOS 3.1, Redfish API, ErP Lot 9, UEFI 2.7, UEFI Class 3, Active Directory v1.0, APML 1.0
Manufacturer Selling Program
HPE Smart Choice
Device Type
Power supply - hot-plug
Power Redundancy Scheme
1+1
Voltage Required
AC 100-120/200-240 V (50/60 Hz)
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
OS Certified
CentOS, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, SuSE Linux Enterprise Server 12 SP3, Red Hat Enterprise Linux 7.4, Red Hat Enterprise Linux 7.5, VMware vSphere 6.5 (ESXi) Update 2, VMware vSphere 6.7 (ESXi)
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Sustainability Information
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Dimensions & Weight (Shipping)
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% RH (non-condensing)
