Product Form Factor
Tower - 4U
Embedded Security
Trusted Platform Module (TPM 2.0) Security Chip
Localisation
Language: English / region: United Kingdom
Bundled with
HP Wolf Pro Security Edition (1 year)
CPU
Intel Core i7 (14th Gen) i7-14700K
Clock Speed
3.4 GHz (P-core) / 2.5 GHz (E-core)
Max Turbo Speed
5.6 GHz (P-core) / 4.3 GHz (E-core)
CPU Upgradability
Upgradable
Processor Main Features
Hyper-Threading Technology, Intel Turbo Boost Technology 2, Intel Smart Cache, Intel Turbo Boost Max 3.0
CPU Socket
LGA1700 Socket
Installed Size
L3 Cache - 33 MB
Cache Per Processor
33 MB
Installed Size
32 GB (installed) / 128 GB (max)
Technology
DDR5 SDRAM - non-ECC
Effective Memory Speed
4800 MHz
Rated Memory Speed
4800 MHz
Slots
4 (Total) / 3 (empty)
Configuration Features
1 x 32 GB
Interface Type
PCI Express 4.0 x4
Features
HP Z Turbo Drive, NVM Express (NVMe), triple-level cell (TLC)
Controller Interface Type
SATA 6Gb/s / PCIe 4.0 x4 (NVMe)
RAID Level
RAID 0, RAID 1
Graphics Processor
Intel UHD Graphics 770 Unified Memory Architecture (UMA)
Video Interfaces
DisplayPort
Compliant Standards
High Definition Audio
Ethernet Controller
Intel I219-LM
Wireless LAN Supported
Yes
Wireless NIC
Intel WI-FI 7 BE200
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6), Bluetooth 5.4, IEEE 802.11be (Wi-Fi 7)
Features
Wake on LAN (WoL), ACPI support, auto-uplink (auto MDI/MDI-X), PXE 2.1 support, Intel Active Management Technology (AMT) 16
Compliant Standards
IEEE 802.3, IEEE 802.3u, IEEE 802.3i, IEEE 802.3z, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.1as, IEEE 802.3az
Bays
1 (total) / 1 (free) x external 5.25" ¦ 1 (total) / 1 (free) x external 5.25" Slim Line ¦ 2 (total) / 2 (free) x internal 3.5" ¦ 1 (total) / 1 (free) x internal 2.5"
Slots
1 (total) / 0 (free) x PCIe 5.0 x16 - full-length, full-height ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 - full-length, full-height (x1 mode, open ended) ¦ 1 (total) / 1 (free) x PCIe 3.0 x4 - full-length, full-height (open ended) ¦ 1 (total) / 1 (free) x PCIe 3.0 x16 - full-length, full-height (x4 mode) ¦ 3 (total) / 2 (free) x M.2 Card - 2280 (for SSD) ¦ 1 (total) / 0 (free) x M.2 Card - 2230 (for WLAN)
Interfaces
1 x headphones/microphone (1 in front) (CTIA and OMTP headset support) ¦ 6 x USB 3.2 Gen 2 (4 front, 2 rear) (one of them is charging) ¦ 1 x audio line-in ¦ 1 x audio line-out ¦ 2 x DisplayPort 1.4 ¦ 3 x USB 2.0 ¦ 1 x USB 3.2 Gen 1 ¦ 1 x LAN (Gigabit Ethernet)
Theft/Intrusion Protection
Security lock slot (cable lock sold separately), padlock loop
Security Slot Type
Kensington security slot
Compliant Standards
RoHS, FIPS 140-2, WEEE, Energy-Related Products (ErP) Lot 6, CECP, SEPA, low halogen
Manufacturer Selling Program
HP Smart Buy
Power Factor Correction
Yes (active)
Operating System / Software
OS Provided
Windows 11 Pro English
Software
HP Support Assistant, HP PC Hardware Diagnostics UEFI, HP Driver Packs, HP Image Assistant, HP PC Hardware Diagnostics, HP ZCentral Remote Boost, HP Management Integration Kit for Microsoft System Center Configuration Manager Gen 4, HP Performance Advisor 3.0
Sustainability Information
ENERGY STAR Certified
Yes
Service & Support
Limited warranty - parts and labour - 3 years - on-site
Dimensions & Weight (Shipping)
Min Operating Temperature
5 °C
Max Operating Temperature
35 °C
Humidity Range Operating
10 - 85% RH (non-condensing)
