Product Form Factor
Tower - 4.5U
Embedded Security
Trusted Platform Module (TPM) Security Chip
Localisation
Region: Germany, Switzerland, Austria, France, United Kingdom, Ireland, Scotland
CPU
Intel Xeon Bronze 3508U
CPU Upgradability
Upgradable
Installed Size
L3 Cache - 22.5 MB
Cache Per Processor
22.5 MB
Installed Size
32 GB (installed) / 1 TB (max)
Technology
DDR5 SDRAM - Advanced ECC
Effective Memory Speed
4400 MHz
Rated Memory Speed
5600 MHz
Slots
16 (Total) / 15 (empty)
Features
Registered, HPE SmartMemory
Configuration Features
1 x 32 GB
Controller Interface Type
SATA 6Gb/s
Storage Controller Name
Intel VROC SATA Software RAID
Ethernet Ports
2 x Gigabit Ethernet
Ethernet Controller
Broadcom BCM5720
Data Link Protocol
Ethernet, Fast Ethernet, Gigabit Ethernet
Remote Management Controller
Integrated Lights-Out 6
Bays
1 (total) / 1 (free) x external 5.25" ¦ 4 (total) / 4 (free) x hot-swap 3.5" LFF
Slots
2 (total) / 2 (free) x PCIe 5.0 x16 ¦ 1 (total) / 1 (free) x PCIe 5.0 x16 / Open Compute Project mezzanine (OCP) 3.0 (x16 mode)
Interfaces
1 x VGA ¦ 2 x LAN (Gigabit Ethernet) ¦ 1 x HPE iLO - RJ-45 (1 rear) ¦ 3 x USB 3.0 (1 front, 2 rear) ¦ 1 x HPE iLO - Type A (1 in front)
Included Accessories
2 non-hot plug standard fans
Compliant Standards
AES, FIPS 140-3, WEEE, Triple DES, TLS v1.2, ASHRAE Class A4, ASHRAE Class A3, Redfish API, UEFI, ACPI 6.4, SMBIOS 3.4
Manufacturer Selling Program
HPE Smart Choice
Device Type
Power supply - hot-plug
Power Redundancy
Optional
Power Redundancy Scheme
1+1 (with optional power supply)
Voltage Required
AC 100-120/200-240 V
80 PLUS Certification
80 PLUS Titanium
Operating System / Software
Software
HPE iLO Standard with Intelligent Provisioning, HPE OneView Standard (free download)
Service & Support
Limited warranty - parts and labour - 3 years - on-site - response time: next business day
Min Operating Temperature
10 °C
Max Operating Temperature
35 °C
Humidity Range Operating
8 - 90% (non-condensing)
