Device Type
Solid state drive - internal
NAND Flash Memory Type
3D quad-level cell (QLC)
Interface
PCIe 4.0 x4 (NVMe)
Features
nCache 4.0 technology
Internal Data Rate
5500 MBps (read) / 5000 MBps (write)
4KB Random Read
690000 IOPS
4KB Random Write
900000 IOPS
Interfaces
1 x PCI Express 4.0 x4 (NVMe)
Power Consumption
75 mW (active) ¦ 5 mW (sleep) ¦ 6.3 mW (average)
Software & System Requirements
Software Included
Acronis True Image WD Edition, Western Digital Dashboard
Compliant Standards
BSMI, CAN ICES-3(B)/NMB3(B), FCC, KCC, Morocco, RCM, TUV, UL, VCCI, ROHS Directive 2011/65/EU, ROHS Directive 2015/863/EU
Service & Support
Limited warranty - 5 years
Min Operating Temperature
0 °C
Max Operating Temperature
85 °C
Min Storage Temperature
-40 °C
Max Storage Temperature
85 °C
Shock Tolerance (operating)
1500 g @ 0.5 ms half-sine
Vibration Tolerance (operating)
5 gRMS @ 10-2000 Hz
Vibration Tolerance (non-operating)
4.9 gRMS @ 7-800 Hz
