Device Type
Solid state drive - internal
NAND Flash Memory Type
Triple-level cell (TLC)
Interface
PCIe 4.0 x4 (NVMe)
Features
nCache 4.0 technology, TCG Pyrite 2.01
Internal Data Rate
4150 MBps (read) / 4150 MBps (write)
4KB Random Read
600000 IOPS
4KB Random Write
750000 IOPS
Interfaces
1 x PCI Express 4.0 x4 (NVMe) - M.2 Card
Power Consumption
65 mW (active) ¦ 3.3 Watt (sleep)
Compliant Standards
BSMI, ICES-3(B)/NMB-3(B), FCC, KCC, Morocco, RCM, TUV, UL, VCCI, CAN
Service & Support
Limited warranty - 5 years
Min Operating Temperature
0 °C
Max Operating Temperature
85 °C
Min Storage Temperature
-40 °C
Max Storage Temperature
85 °C
Shock Tolerance (operating)
1500 g @ 0.5 ms half-sine
Vibration Tolerance (operating)
5 g @ 10-2000 Hz
Vibration Tolerance (non-operating)
4.9 g @ 7-800 Hz
