Crestron TSW-1070-B-S - control panel with touch s

Images Manuals

Images for illustrative purposes

Crestron TSW-1070-B-S

Name: Crestron TSW-1070-B-S
Brand: CRESTRON ELECTRONICS
SKU: ECE10400005
Price: 2645.00 EUR
Availability: OutOfStock

View all CRESTRON ELECTRONICS Home Automations - Visit the CRESTRON ELECTRONICS Store (TSW-1070-B-S) - (ECE10400005)

Model: Crestron

Crestron TSW-1070-B-S - Control panel with touch screen - wireless, wired - Bluetooth, 802.11a/b/g/n/ac - 2.4 Ghz, 5 GHz - 10/100 Ethernet - smooth black

High-definition display
Versatile connectivity
Enhanced security
Intuitive operation
Robust environmental adaptability

FREE Delivery on orders over €250

0 Available to Ship
Restock 10-Jul-2026 Estimated, Out of Stock Prices are Estimated.

RRP ~~€4607.58~~

€2645.00 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The Crestron TSW-1070-B-S control panel is designed to enhance any integrated system or automation setup. With its 10.1-inch Full HD touchscreen, users are treated to a visually stunning interface that is both responsive and intuitive. The display supports 24-bit color, ensuring that every detail is presented with clarity and vibrancy.

This control panel is built for performance. With dual connectivity options, users can choose between wired and wireless connections, including Bluetooth and 802.11a/b/g/n/ac Wi-Fi, making it a versatile choice for any environment. Security is a priority, with multiple encryption standards supported, including AES and SSL, to protect sensitive information.

Ease of use is enhanced by voice recognition capabilities and Smart Graphics support, allowing for seamless interaction. Whether mounted on the wall or placed on a desk, its sleek design and edge-to-edge glass make it a stylish addition to any space. Moreover, its robust build is capable of operating in a wide range of temperatures and humidity levels, ensuring reliable performance where it matters most.

Specification Summary

Product Description

Crestron TSW-1070-B-S - control panel with touch screen - Bluetooth, 802.11a/b/g/n/ac - smooth black

Product Type

Control panel with touch screen

Placing / Mounting

Wall-mounting

Integrated Components

Microphone, speaker, SIP intercom

Power Source

PoE

Connectivity

Wireless, wired - Bluetooth, 802.11a/b/g/n/ac - 10/100 Ethernet

Frequency Band

2.4 Ghz, 5 GHz

Input Type

6 buttons

Display

10.1" - TFT - 24-bit colour - Yes

Colour

Smooth black

Dimensions (WxDxH)

24 cm x 5.1 cm x 14.9 cm

Specifications

EAN / GTIN:

8592978578244

General

Product Type

Control panel with touch screen

Integrated Components

Microphone, speaker, SIP intercom

Power Source

PoE

Placing / Mounting

Wall-mounting

Connectivity Technology

Wireless, wired - Ethernet, Fast Ethernet, Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac

Max Range Open Space

15 m

Frequency Band

2.4 Ghz, 5 GHz

Display

10.1" - TFT - 24-bit colour

Display Resolution

1920 x 1080 pixels

Touchscreen

Yes

Interfaces Details

LAN ¦ 2 x USB 2.0

Features

Brightness control, Smart Graphics support, voice recognition capability, H.264 streaming video, MJPEG streaming video, edge-to-edge, H.265 streaming video, 400 cd/m2 brightness, 1000:1 contrast, projected capacitive touch screen, PoE+, DHCP support, auto-negotiation, IPv6 support, half duplex mode, full duplex mode, SSH support, IPv4 support, SNMP support, auto-switching, CIP support, RTSP support, UDP support, TCP support

Control Unit

Buttons Qty

RAM

Installed Size

2 GB

Flash Memory

Installed Size

16 GB

Miscellaneous

Product Material

Plastic

Colour

Smooth black

Encryption Algorithm

AES, 128-bit WEP, 64-bit WEP, SSL, TLS, TKIP, WPA, WPA2-PSK

Compliant Standards

IC, DIN 49073, FCC Part 15 Class B, IEEE 802.3at, BS 4662, IEEE 802.1x

Dimensions & Weight

Width

24 cm

Depth

5.1 cm

Height

14.9 cm

Weight

730 g

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

10 - 95% (non-condensing)
