Crestron Room Scheduling Touch Screen TSS-1070-W-S

Images Manuals

Crestron Room Scheduling Touch Screen TSS-1070-W-S-LB KIT

Images for illustrative purposes

Crestron Room Scheduling Touch Screen TSS-1070-W-S-LB KIT

- Visit the CRESTRON ELECTRONICS Store (TSS-1070-W-S-LB KIT) - (MMECK55427)

Crestron Room Scheduling Touch Screen TSS-1070-W-S-LB KIT - room manager - Bluetooth, 802.11a/b/g/n/ac - smooth white

Functional
Versatile
Reliable
Secure
Manageable
Cost‑effective

FREE Delivery on orders over €250

2 Available to Ship
Order within 22Hrs 21Mins for: FREE Delivery (9 Jun or 10 Jun)

€1203.31 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Crestron TSS-1070 series touch screens are designed to enhance and simplify room scheduling across an enterprise. The TSS-1070 installs near the entrance of a meeting room or huddle space to provide a clear indication of the room availability and schedule, and it integrates seamlessly with a variety of popular scheduling services. The TSS-1070-LB KIT includes one TSW‑1070‑LB series room availability light bar with the touch screen, providing for a complete room scheduling solution.

Features Summary

Functional
The TSS-1070 provides everything needed for scheduling applications in one compact unit that mounts over a standard electrical box or cutout. The TSS-1070 offers high‑speed Ethernet and PoE/PoE+ connectivity, or, for deployments without access to Ethernet, it can be connected the network over Wi‑Fi communications via a local wireless access point (WAP).
Versatile
Crestron offers a variety of mounting options for mounting the TSS-1070 to drywall, masonry, glass, mullions, and other surfaces.
Reliable
Consumer tablets are meant for mobile handheld use and not permanent installs. By contrast, Crestron touch screens are purpose‑built for permanent installation and years of reliable 24/7 operation in a commercial environment.
Secure
Crestron touch screens employ enterprise-grade networking with robust security features such as 802.1X authentication, TLS encryption, HTTPS connectivity, and Active Directory service integration. These features protect your network against service interruptions and malicious intrusions and ensure compliance with your organization's network policies.
Manageable
Crestron touch screens feature cloud‑based provisioning and management to streamline the process of configuring and monitoring every touch screen on the network and keeping them updated. They also support SNMP, so they can be monitored by your IT administrator alongside every other device on the network.
Cost‑effective
Crestron touch screens offer clear advantages over other alternatives, but that doesn't mean they cost more. The TSS-1070 series delivers a comparable or lower cost solution compared to buying tablets with all the extra peripherals and maintenance they require.

Specification Summary

Product Description

Crestron Room Scheduling Touch Screen TSS-1070-W-S-LB KIT - room manager - Bluetooth, 802.11a/b/g/n/ac - smooth white

Product Type

Room manager wall mount

Placing / Mounting

Wall-mounting

Integrated Components

Speaker

Power Source

PoE

Package Content

Light bar

Connectivity

Wireless, wired - Bluetooth, 802.11a/b/g/n/ac - 10/100 Ethernet

Frequency Band

2.4 Ghz, 5 GHz

Input Type

6 buttons - touch screen

Display

10.1" - TFT - 24-bit colour

Colour

Smooth white

Dimensions (WxDxH)

25.9 cm x 5.8 cm x 14.9 cm

Specifications

General

Product Type

Room manager wall mount

Integrated Components

Speaker

Power Source

PoE

Placing / Mounting

Wall-mounting

Package Content

Light bar

Connectivity Technology

Wireless, wired - Ethernet, Fast Ethernet, Bluetooth, IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac

Max Range Open Space

15 m

Frequency Band

2.4 Ghz, 5 GHz

Display

10.1" - TFT - 24-bit colour

Display Resolution

1920 x 1200 pixels

Interfaces Details

LAN/power ¦ 2 x USB 2.0

Features

Brightness control, reset button, edge-to-edge, capacitive touch screen, 400 cd/m2 brightness, PoE+, DHCP support, auto-negotiation, IPv6 support, half duplex mode, full duplex mode, SSH support, IPv4 support, SNMP support, auto-switching, CIP support, UDP support, TCP support

Control Unit

Input Type

Touch screen

Buttons Qty

Miscellaneous

Product Material

Plastic

Colour

Smooth white

Encryption Algorithm

AES, 128-bit WEP, 64-bit WEP, SSL, TLS, TKIP, WPA, WPA2-PSK

Compliant Standards

IC, DIN 49073, FCC Part 15 Class B, IEEE 802.3at, BS 4662, IEEE 802.1x

Dimensions & Weight

Width

25.9 cm

Depth

5.8 cm

Height

14.9 cm

Weight

730 g

Environmental Parameters

Min Operating Temperature

5 °C

Max Operating Temperature

40 °C

Humidity Range Operating

10 - 90% (non-condensing)
