QNAP TS-1273AU-RP

View all QNAP NAS and Network Drives - Visit the QNAP Store (TS-1273AU-RP-8G) - (ECE7766849)

TS-1273AU-RP - NAS server - 12 bays - rack-mountable - SATA 6Gb/s - RAID 0, 1, 5, 6, 10, JBOD, 5 hot spare, 6 hot spare, 10 hot spare - RAM 8 GB - Gigabit Ethernet / 2.5 Gigabit Ethernet - iSCSI support - 2U

Absolute performance with AMD Ryzen and up to 32GB RAM
Block-based iSCSI LUN: Ideal choice for virtualization storage
Optimized performance for VMware Virtualization with iSER
All-in-one server to host virtual machines and containers
Abundant I/O capabilities with PCIe expansion
GPU-accelerated computing

HOT

FREE Delivery on orders over €250

0 Available to Ship
Restock 24-Aug-2026 Estimated, Out of Stock Prices are Estimated.

RRP ~~€6018.38~~

€3456.28 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

With its powerful AMD Ryzen V1000 series V1500B Quad-core processor, the TS-1273AU-RP is capable of boosting virtual machine performance with up to 4 cores/8 threads at 2.2GHz. The TS-1273AU-RP includes two 2.5GbE ports and two PCIe Gen 3 slots, providing you with fast network connectivity and the ability to add extra functionality and additional application potential. The TS-1273AU-RP also features a redundant power supply to ensure maximum system uptime. Cutting-edge hardware integrated with comprehensive software solutions makes the TS-1273AU-RP the preeminent choice to tackle resource-demanding applications and tasks.

Features Summary

Absolute performance with AMD Ryzen and up to 32GB RAM
Powered by a 4-core/8-thread AMD Ryzen V1500B 2.2GHz processor with AES-NI encryption acceleration and up to 32GB DDR4 RAM, the rackmount TS-1273AU-RP delivers aggressive yet power-smart performance to drive resource-demanding business applications such as VDI, R&D, private cloud, and server virtualization.
Block-based iSCSI LUN: Ideal choice for virtualization storage
The TS-1273AU-RP supports block-based iSCSI LUN and is compatible for VMware, Citrix, Microsoft Hyper-V, and Windows Server 2019 virtualization environments to provide a high-performance and affordable storage solution. The TS-1273AU-RP also supports VMware VAAI and Microsoft ODX to increase performance by offloading server loading for ESXi server and Hyper-V respectively, and supporting QNAP vSphere Client plug-in with enhanced operational efficiency and management in virtualization applications.
Optimized performance for VMware Virtualization with iSER
The iSCSI Extensions for RDMA (iSER) protocol boosts the data transfer performance of VMware ESXi storage and reduces the CPU load of the ESXi server. iSER support can be added to the TS-1273AU-RP by installing a QNAP QXG-10G2SF-CX4 10GbE PCIe card, which uses the Mellanox ConnectX-4 controller. iSER can provide a significant increase in performance, providing an essential tool to optimize demanding virtualization applications.
All-in-one server to host virtual machines and containers
Regardless of your virtualization needs, you can count on Virtualization Station and Container Station for complete virtualization support. Use the Network & Virtual Switch app to allocate adequate physical network resources to virtual machines, containers, and the TS-1273AU-RP to simplify network deployment.
Abundant I/O capabilities with PCIe expansion
The TS-1273AU-RP includes two PCIe Gen 3 x4 slots, allowing you to add additional functionality with compatible PCIe cards. By using a suitable adapter, you can consolidate both slots into a single PCIe Gen 3 x8 slot.
GPU-accelerated computing
Graphics cards are optimized for graphical calculations and transformations, but require significantly more power than other hardware. The TS-1273AU-RP supports entry-level low-profile NVIDIA GeForce graphics cards (such as the GT 1030 or GT 1050) that do not require additional power. Installing a graphics card can boost performance of applications such as video editing, 4K video transcoding, imaging processing in QTS and the performance of virtual machines via GPU passthrough.

Specification Summary

Product Description

QNAP TS-1273AU-RP - NAS server

Device Type

NAS server

Host Connectivity

Gigabit Ethernet / 2.5 Gigabit Ethernet

Enclosure Type

Rack-mountable - 2U

Installed Devices / Modules Qty

0 (installed) / 12 (max)

Dimensions (WxDxH)

43.2 cm x 37.2 cm x 8.9 cm

Weight

9.69 kg ()

Processor

1 x AMD Ryzen Embedded V1500B 2.2 GHz (Quad-Core)

Storage Controller

RAID SATA 6Gb/s RAID 0, 1, 5, 6, 10, JBOD, 5 hot spare, 6 hot spare, 10 hot spare

Networking

10Mb LAN, 100Mb LAN, 1GbE, 2.5GbE

RAM

8 GB

Power

AC 120/230 V (50/60 Hz)

Power Redundancy

Yes

Storage Operating System

QNAP QTS 4.4.2

System Requirements

UNIX, Linux, Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Apple MacOS X 10.7 or later, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows 7 / 8 / 10

Specifications

EAN / GTIN:

4713213517901

General

Device Type

NAS server

Host Connectivity

Gigabit Ethernet / 2.5 Gigabit Ethernet

Enclosure Type

Rack-mountable - 2U

Total Storage Capacity

0 GB

Installed Devices / Modules Qty

0 (installed) / 12 (max)

Width

43.2 cm

Depth

37.2 cm

Height

8.9 cm

Weight

9.69 kg ()

Processor / Memory

Processors Installed

1 x AMD Ryzen Embedded V1500B 2.2 GHz

Number of Cores

Quad-Core

Max Supported Qty

RAM

8 GB (installed) / 32 GB (supported) - DDR4

Flash Memory Installed

5 GB

Storage Controller

Type

RAID

Interface Type

SATA 6Gb/s

RAID Level

RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD, RAID 5 hot spare, RAID 6 hot spare, RAID 10 hot spare

Networking

Data Link Protocol

10Mb LAN, 100Mb LAN, 1GbE, 2.5GbE

Network / Transport Protocol

TCP/IP, PPTP, UDP/IP, iSCSI, SMTP, FTP, DHCP, Bonjour, SMB, DDNS

Remote Management Protocol

SNMP 2, Telnet, SNMP 3, HTTP, HTTPS, TFTP, SSH

Network Services Compatibility

Microsoft Active Directory (AD), Apple Bonjour Protocol, DHCP, DDNS, Microsoft CIFS, Network File System (NFS), FTP, FTPS, Server Message Block (SMB), Apple File Protocol (AFP), HTTP, HTTPS, Web-based Distributed Authoring and Versioning (WebDAV)

Features

NAT support, trunking, LDAP support, WOL, Syslog support, E-mail alert, print server, IPv6 support, STP support, download client, file sharing, TFTP support, SSH support, iTunes server, Jumbo Frames support, DHCP server, FTP server, SMS alert, BitTorrent Client, UPnP Media Server, bandwidth control, surveillance station, teaming support, DLNA Media Server, Apple Time Machine compatible, DHCP client, e-mail notification, cloud backup, VPN Server, Apple AirPlay, event notification, push notification, Chromecast support

Encryption Algorithm

SSL, FIPS 140-2, 256-bit AES, AES-NI

Compliant Standards

UPnP

Expansion / Connectivity

Expansion Bays

12 (total) / 12 (free) x hot-swap - 2.5" / 3.5"

Expansion Slots

2 (total) / 1 (free) x DIMM 288-pin ¦ 2 (total) / 2 (free) x PCI Express 3.0 x4

Interfaces

2 x 2.5 Gigabit Ethernet - RJ-45 ¦ 1 x USB 3.2 Gen 1 - Type A ¦ 2 x USB 3.2 Gen 2 - Type C ¦ 1 x USB 3.2 Gen 2 - Type A

Miscellaneous

Cables Included

1 x network cable

Features

Audible alarm, wake on LAN

Included Accessories

36 x flat head screws (for 2.5" HDD), 48 x flat head screws (for 3.5" HDD), 2 x power cables

Power

Power Device

Internal power supply

Installed Qty

Max Supported Qty

Power Redundancy

Yes

Voltage Required

AC 120/230 V (50/60 Hz)

Power Consumption Operational

78.92 watt

Power Consumption Stand by

43.67 watt

Power Provided

300 watt

Software / System Requirements

Storage Operating System

QNAP QTS 4.4.2

OS Required

Dimensions & Weight (Shipping)

Shipping Weight

14.62 kg

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

5 - 95% (non-condensing)
