ViewSonic TD2223 - LED monitor - Full HD (1080p) -

Images Manuals

Images for illustrative purposes

ViewSonic TD2223

View all VIEWSONIC Monitors - Visit the VIEWSONIC Store (TD2223) - (MMECA69875)

TD2223 - LED monitor - Full HD (1080p) - 22"

Intuitive multi-touch experience
Simple and safer way to Interact
Anti-scratch touchscreen
Adjustable tilt
Clear images
Dual integrated speakers
View More
Enhanced viewing comfort

FREE Delivery on orders over €250

**Please read important notice on dead pixel tolerences in the returns portion of the help page before purchasing - Help Page

2 Available to Ship
Order within 9Hrs 0Mins for: FREE Delivery (8 Jun or 9 Jun)

€259.75 Incl Vat

Bulk Pricing from €251.95

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The ViewSonic TD2223 is a 22" IR touch display designed for intuitive multi-touch use. Infrared (IR) touchscreen can detect up to 10 points of contact compared to optical touchscreens and can be operated by a stylus, fingers and gloved hands. The multi-touch input is more accurate, and the display is faster. Coupled with an adjustable tilt, you can easily interact with the TD2223 at an ideal position. This monitor features Full HD resolution to give you clear images and is built with scratch-resistant 7H hardness screen to surface damage. To support your work, the TD2223 is equipped with VGA, HDMI, DVI and USB connectivity.

Specification Summary

Product Description

ViewSonic TD2223 - LED monitor - Full HD (1080p) - 22"

Device Type

LED-backlit LCD monitor - 22" - touchscreen

Energy Label QR Code URL

Https://eprel.ec.europa.eu/qr/1781306

Energy Class

Class E

Power Consumption (On mode)

15.4 W

Features

Touch-screen, USB 2.0 hub

Panel Type

Aspect Ratio

16:9

Native Resolution

Full HD (1080p) 1920 x 1080 at 75 Hz

Brightness

250 cd/m²

Contrast Ratio

1000:1 / 20000000:1 (dynamic)

Response Time

5 ms (grey-to-grey)

Colour Support

16.7 million colours (8-bit)

Colour Gamut

103% sRGB, 72% NTSC

Input Connectors

HDMI, DVI-D, VGA

Display Position Adjustments

Tilt

Screen Coating

7H Hard Coating

Voltage

AC 120/230 V (50/60 Hz)

Dimensions (WxDxH) - with stand

52.1 cm x 10.1 cm x 33.4 cm

Weight

4.5 kg

Environmental Standards

ENERGY STAR Qualified EPEAT Silver

Compliant Standards

FCC Class B certified, BSMI, ICES-003, CB, CCC, RoHS, WEEE, PSE Mark, cTUVus, REACH, CEC, UkrSEPRO, ERP, CECP, EAC, China Energy Label, China RoHS, RCM, GEMS, CE/EMC, Mexico Energy label, Mexico CoC

Manufacturer Warranty

3-year warranty

Specifications

EAN / GTIN:

0766907008647

General

Display Type

LED-backlit LCD monitor / TFT active matrix

Energy Label QR Code URL

Https://eprel.ec.europa.eu/qr/1781306

Energy Class

Class E

Diagonal Size

22"

Viewable Size

21.5"

Built-in Devices

USB 2.0 hub

Panel Type

Aspect Ratio

16:9

Native Resolution

Full HD (1080p) 1920 x 1080 at 75 Hz

Brightness

250 cd/m²

Contrast Ratio

1000:1 / 20000000:1 (dynamic)

Colour Support

16.7 million colours (8-bit)

Colour Gamut

103% sRGB, 72% NTSC

Response Time

5 ms (grey-to-grey)

Vertical Refresh Rate

50 - 75 Hz

Horizontal Refresh Rate

24 - 82 kHz

Horizontal Viewing Angle

170

Vertical Viewing Angle

160

Screen Coating

7H Hard Coating

Backlight Technology

LED backlight

Features

Eco-Mode, glossy, scratch-resistant, Flicker Free technology, glove touch mode, Bluelight Filter, Eye-Care Technology, infrared touch technology, 8-bit(6-bit + Hi-FRC) Colour Depth

Dimensions (WxDxH)

52.1 cm x 10.1 cm x 33.4 cm - with stand

Weight

4.5 kg

Audio

Type

Speakers - stereo

Output Power / Channel

2 watt

Input

Type

Touch-screen - touchscreen

Movement Detection Technology

Infrared

Connectivity

Interfaces

VGA ¦ 2 x USB 2.0 downstream (Type A) ¦ USB 2.0 upstream (Type B) ¦ Audio line-in (mini-jack) ¦ Audio line-out (mini-jack) ¦ HDMI ¦ DVI-D

Mechanical

Display Position Adjustments

Tilt

Tilt Angle

VESA Mounting Interface

100 x 100 mm

Miscellaneous

Features

Security lock slot (cable lock sold separately)

Included Accessories

Cable management cover

Cables Included

1 x audio cable ¦ 1 x HDMI cable ¦ 1 x USB-A to USB-B cable

Backlight Life

30,000 hours

Compliant Standards

FCC Class B certified, BSMI, ICES-003, CB, CCC, RoHS, WEEE, PSE Mark, cTUVus, REACH, CEC, UkrSEPRO, ERP, CECP, EAC, China Energy Label, China RoHS, RCM, GEMS, CE/EMC, Mexico Energy label, Mexico CoC

Security Slot Type

Kensington security slot

Power

Input Voltage

AC 120/230 V (50/60 Hz)

Power Consumption (On mode)

15.4 W

Power Consumption SDR (On mode)

15 kWh/1000h

Power Consumption (Typical)

12.5 watt

Power Consumption Stand by

0.5 watt

Software / System Requirements

OS Required

Apple MacOS, Linux, Android, Google Chrome OS, Windows 10

Dimensions & Weight

Dimensions & Weight Details

With stand - width: 52.1 cm - depth: 10.1 cm - height: 33.4 cm - weight: 4.5 kg ¦ Without stand - width: 52.1 cm - depth: 6.1 cm - height: 31.8 cm - weight: 3.9 kg

Dimensions & Weight (Shipping)

Shipping Width

58 cm

Shipping Depth

16.4 cm

Shipping Height

40.5 cm

Shipping Weight

6 kg

Sustainability Information

EPEAT Compliant

EPEAT Silver
