Startech 4 Port Gigabit PoE (Power over Ethernet) Card

Images for illustrative purposes

Startech 4 Port Gigabit PoE (Power over Ethernet) Card

View all STARTECH.COM PCI / M.2 Cards and Adapters - Visit the STARTECH.COM Store (ST4000PEXPSE) - (WCEST4000PEXPSE)

Startech 4 Port Gigabit PoE (Power over Ethernet) Card - PCIe Network Card - PoE / PoE+ Up to 25W Per Port - PCIe NIC - Gigabit Ethernet Card (ST4000PEXPSE) - network adapter - PCIe x4 - Gigabit Ethernet x 4

Reliable connectivity
Flexible power delivery
Durable design
Enhanced performance
Easy installation

FREE Delivery on orders over €250

5 Available to Ship
Order within 16Hrs 7Mins for: FREE Delivery (8 Jun or 9 Jun)

RRP ~~€390.67~~

€349.75 Incl Vat

Price at 30 Day Low

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

Add 4 Gigabit Power over Ethernet ports to a PCI Express-enabled computer. The ST4000PEXPSE 4-Port PoE NIC lets you add four Gigabit Power over Ethernet ports through a single PCI Express slot. Each port can provide up to 25.5W of power, combining network data and power over a single Ethernet cable for reduced cable clutter and added convenience for remote PoE devices.

The PCI express PoE card supports the IEEE 802.3at (Type 1 and 2) standard for Power Sourcing Equipment (PSE), and can deliver up to 48V DC power to compliant Powered Devices (PD). This eliminates the need for a separate power source and data connection for PoE devices such as IP cameras, IP phones or wireless access points.

Suitable for any standard profile PCIe-enabled client, server or workstation, the PoE network card supports features such as Jumbo Frames (up to 9KB), VLAN tagging and Wake on LAN (WoL).

Features Summary

Reliable connectivity
This network card interfaces via PCI Express x4, ensuring stable wired connections with speeds up to 1 Gbps and compliance with multiple networking standards including IEEE 802.3.
Flexible power delivery
Capable of PoE/PoE+ delivery, this card eliminates the need for additional power sources by powering devices directly through the network cable.
Durable design
With an operating temperature range from 0°C to 55°C and capable of handling humidity levels from 10% to 90% (non-condensing), this network card is built to perform in various environments.
Enhanced performance
The card supports Jumbo Frames and features a 48KB packet buffer, allowing efficient data handling for intensive applications.
Easy installation
The plug-in design simplifies integration into existing systems while the auto-uplink feature automatically adjusts for seamless network configuration.

Specification Summary

Product Description

Device Type

Network adapter

Form Factor

Plug-in card

Interface (Bus) Type

PCI Express x4

Ports

Gigabit Ethernet x 4

Dimensions (WxDxH)

12 cm x 24 cm x 1.8 cm

Cabling Type

Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T

Data Link Protocol

10Mb LAN, 100Mb LAN, 1GbE

Data Transfer Rate

1 Gbps

Processor

Realtek Semiconductor RTL8111E

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az

System Requirements

Microsoft Windows Server 2003, Microsoft Windows Server 2008 R2, Microsoft Windows Server 2012, Microsoft Windows Server 2012 R2, Microsoft Windows Server 2016, Microsoft Windows 2000/XP/Vista/7/8/8.1/10, Linux 2.4.x to 4.11.x LTS versions only, Microsoft Windows Server 2019

Manufacturer Warranty

2-year warranty

Specifications

EAN / GTIN:

0065030855150

General

Device Type

Network adapter

Form Factor

Plug-in card

Interface (Bus) Type

PCI Express x4

Networking

Ports

Gigabit Ethernet x 4

Connectivity Technology

Wired

Cabling Type

Ethernet 10Base-T, Ethernet 100Base-TX, Ethernet 1000Base-T

Data Link Protocol

Ethernet, Fast Ethernet, Gigabit Ethernet

Data Transfer Rate

1 Gbps

Status Indicators

PoE, link/activity

Features

Full duplex capability, PoE, auto-uplink (auto MDI/MDI-X), Jumbo Frames support, 48KB packet buffer

Compliant Standards

IEEE 802.3, IEEE 802.3u, IEEE 802.1Q, IEEE 802.3ab, IEEE 802.1p, IEEE 802.3af, IEEE 802.3x, IEEE 802.3at, IEEE 802.3az

Processor / Memory

Processor

Realtek Semiconductor RTL8111E

Expansion / Connectivity

Interfaces

4 x 1000Base-T (PoE) - RJ-45 (external) ¦ 1 - 4 PIN internal power (internal) ¦ 1 - 15 pin Serial ATA power (internal)

Miscellaneous

Compliant Standards

FCC, RoHS

Software / System Requirements

Software Included

Drivers & Utilities

OS Required

Dimensions & Weight

Width

12 cm

Depth

24 cm

Height

1.8 cm

Manufacturer Warranty

Service & Support

Limited warranty - 2 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

55 °C

Humidity Range Operating

10 - 90% (non-condensing)
