APC Easy UPS SRV SRV6KRIL

Name: APC Easy UPS SRV SRV6KRIL
Brand: APC
SKU: ECE4977161
Price: 4316.57 EUR
Availability: OutOfStock

View all APC Uninteruptable Power Supply - Visit the APC Store (SRV6KRIL) - (ECE4977161)

Model: APC Easy

Please contact sales for freight costs

Intelligent Card Slot
Serial connectivity
Serial connectivity
Intelligent battery management

FREE Delivery on orders over €250

**Note: There may be an extra delivery charge on some very large UPS, we will notify you if this is the case. Please ensure you are buying the correct UPS or Battery, once a UPS or Battery is opened it cannot be returned. Please contact sales through email, chat or phone if you need to confirm.

0 Available to Ship
Restock 25-Aug-2026 Estimated, Out of Stock Prices are Estimated.

RRP ~~€5750.25~~

€4316.57 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

This APC Single phase Easy UPS is designed for IT professionals or network administrators to maintain business uptime and continuity. This 6kVA double-conversion on-line 5U rackmount UPS provides pure sine wave power and extended runtime to support critical electronics during power disruptions. The SRV comes with hard wire 3-wire(1P+N+E) input and hard wire 3-wire(1P+ N+E) outlet. The On-Line UPS has a intelligent card slot for optional Network Management Card (AP9544, SRVSMB001, VGL9901l) that enables network-based UPS monitoring and management. The UPS can connect to EcoStruxure IT or third-party centralized management platforms. The Built-in automatic and manual bypass provide seamless power to the load even in the event of an internal detected fault or error in UPS. The UPS is compatible with SRVRK1 and SRVRK2 rail kits sold separately. The UPS and the built-in lead-acid battery has a 2-year warranty. Ideal for small data centers, manufacturing facilities, computer rooms, network storage devices, telecommunication, and healthcare IT.

Features Summary

Text and mimic diagrams that display modes of operation, system parameters and alarms.
Mini slot supports various optional management cards which provide basic or essential monitoring, management and control features for the UPS.
Intelligent Card Slot
Mini slot supports various optional management cards which provide basic or essential monitoring, management and control features for the UPS.
Operating mode that by-passes unused electrical components in good power conditions to achieve high operating efficiency without sacrificing protection.
Full color text and mimic diagrams that easily display modes of operation, systems parameters and alarms.
Serial connectivity
Use any Home Automation network to monitor and control the S20 through its RS-232 serial port. For information on how to communicate with the S20, see APC's Application Note #102. Crestron and AMX installers should visit their respective websites for information on how to integrate the S20 into those networks.
Supplies utility power to the connected loads in the event of a UPS power overload or fault.
Registering license keys unlocks the features of the data center management software.
Automatically starts up the connected equipment upon the return of utility power.
Periodic battery self-test ensures early detection of a battery that needs to be replaced.
Minimizes installation costs by enabling the use of smaller generators and cabling.
Prevents unauthorized access to the UPS.
Serial connectivity
Provides management of the UPS via a serial port.
Provides management of the UPS via a USB port (not available on all models).
Increases availability by allowing a trained user to perform upgrades and replacements of the batteries reducing Mean Time to Repair (MTTR)
Intelligent battery management
Maximizes battery performance, life, and reliability through intelligent, precision charging.

Specification Summary

Product Description

APC Easy UPS SRV SRV6KRIL - UPS - 6000 watt - 6000 VA - with External Battery Pack

Device Type

UPS - rack-mountable

Rack Size

Weight

61 kg

Input Wiring

1-phase

Input Voltage

AC 220-240 V

Output Voltage

AC 220/230/240 V ± 1%

Power Capacity

6000 watt / 6000 VA

Input Connectors

1 x terminal block

Output connectors

1 x terminal block

Battery

Lead Acid

Batteries Qty

Networking

USB, RS-232

Dimensions (WxDxH)

43.8 cm x 71 cm x 17.3 cm

Manufacturer Warranty

2-year warranty

Bundled with

External Battery Pack

Specifications

EAN / GTIN:

8592978281045

General

Device Type

UPS - rack-mountable

Height (Rack Units)

Bundled with

External Battery Pack

Power Device

UPS Technology

On-line

Input Voltage

AC 220-240 V

Input Voltage Range

AC 110 - 300 V

Frequency Provided

50/60 Hz ± 4Hz

Input Wiring

1-phase

Frequency Required

50/60 Hz

Input Connectors

1 x terminal block

Power Output Connectors Details

1 x terminal block

Output Voltage

AC 220/230/240 V ± 1% - 50/60 Hz

Power Capacity

6000 watt / 6000 VA

Output Waveform

Sinewave

Surge Energy Rating

600 joules

Circuit Protection

Circuit breaker

Efficiency

94% AC mode

Power Factor (PF)

0.99

Battery

Quantity

Technology

Lead Acid

Features

Sealed, maintenance free

Networking

Remote Management Interface

USB, RS-232

Expansion / Connectivity

Interfaces

1 x management (USB) ¦ 1 x management (RS-232) ¦ EPO (emergency power off)

Miscellaneous

Cables Included

USB cable

Features

LCD display, Eco-Mode, generator compatible, over voltage protection, internal bypass, firmware upgradable

Software / System Requirements

Software Included

APC Easy Ups Online SNMP Shutdown Wizard

Manufacturer Warranty

Service & Support

Limited warranty - 2 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

0 - 95% (non-condensing)

Sound Emission

58 dB

Dimensions & Weight

Width

43.8 cm

Depth

71 cm

Height

17.3 cm

Weight

61 kg

Dimensions & Weight (Shipping)

Shipping Weight

71 kg
