APC Smart-UPS Ultra - UPS - online - 10000 Wh - 10

Images Manuals

Images for illustrative purposes

APC Smart-UPS Ultra

Name: APC Smart-UPS Ultra
Brand: APC
SKU: ECE9044615
Price: 14965.68 EUR
Availability: InStock

View all APC Uninteruptable Power Supply - Visit the APC Store (SRTL10KRM4UI) - (ECE9044615)

Model: APC Smart-UPS

Smart-UPS Ultra - UPS (rack-mountable) (high density) - online - AC 230 V - 10000 Wh - 10000 VA - Lithium Ion - output connectors: 12 - 4U - silver grey

Efficient power management
Versatile connectivity
Optimal environmental adaptability
Comprehensive protection standards
Enhanced monitoring and control

FREE Delivery on orders over €250

**Note: There may be an extra delivery charge on some very large UPS, we will notify you if this is the case. Please ensure you are buying the correct UPS or Battery, once a UPS or Battery is opened it cannot be returned. Please contact sales through email, chat or phone if you need to confirm.

8 Available to Ship
Order within 16Hrs 8Mins for: FREE Delivery (8 Jun or 9 Jun)

RRP ~~€20049.00~~

€14965.68 Incl Vat

Price at 30 Day Low

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

"With Smart-UPS Ultra you can put up to 10000W of power protection in places never before possible." "Make installation effortless with a 10kW UPS that is 30% smaller and lighter than any comparable UPS." "The auto-rotating touch screen display makes switching between horizontal and vertical mounting options instantaneous." "Lithium-ion batteries provide reduced maintenance cost with 3x the battery life." "EcoStruxure Ready Smart-UPS provides visibility anywhere, anytime."

Specification Summary

Product Description

APC Smart-UPS Ultra - UPS - online - 10000 Wh - 10000 VA - Li-Ion

Device Type

UPS - rack-mountable

Rack Size

Weight

55 kg

Input Voltage

AC 230 V

Output Voltage

AC 220/230/240 V

Power Capacity

10000 Wh / 10000 VA

Input Connectors

1 x power IEC 60320 C14

Output connectors

6 x power IEC 60320 C13 ¦ 6 x power IEC 60320 C19

Battery

Lithium ion high density - Lithium Ion

Run Time (Up To)

5 min at full load

Colour

Silver grey

Dimensions (WxDxH)

43.2 cm x 83.2 cm x 17.5 cm

Manufacturer Warranty

5-year warranty

Specifications

EAN / GTIN:

731304578505

General

Device Type

UPS - rack-mountable

Height (Rack Units)

Colour

Silver grey

Power Device

UPS Technology

On-line

Input Voltage

AC 230 V

Frequency Provided

50/60 Hz ± 3Hz

Input Connectors

1 x power IEC 60320 C14

Power Output Connectors Details

6 x power IEC 60320 C13 ¦ 6 x power IEC 60320 C19

Output Voltage

AC 220/230/240 V 50/60 Hz

Power Capacity

10000 Wh / 10000 VA

Output Waveform

Sinewave

Battery

Type

High density

Technology

Lithium Ion lithium ion

Voltage Provided

180 V

Recharge Time

1.5 hours

Expansion / Connectivity

Interfaces

1 x - hardwire 3-wire (1P+ N + E)

Miscellaneous

Cables Included

USB cable - external

Rack Mounting Kit

Included

Features

Horizontal mount, vertical mount, emergency power off, audible alarm, visible alarm, internal bypass, LCD display

Compliant Standards

UKCA, IEC/EN 62040-1, IEC/EN 62040-2, IEC 62040-2, EU RoHS, China RoHS, REACH, IP20, VDE

Manufacturer Warranty

Service & Support

Limited warranty - 5 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

0 - 95% (non-condensing)

Sound Emission

55 dBA

Dimensions & Weight

Width

43.2 cm

Depth

83.2 cm

Height

17.5 cm

Weight

55 kg

Dimensions & Weight (Shipping)

Shipping Width

65 cm

Shipping Depth

100 cm

Shipping Height

63 cm

Shipping Weight

88.5 kg
