EAN / GTIN:
8806097729075
Energy Label QR Code URL
Https://eprel.ec.europa.eu/qr/2284558
Manufacturer Model Number
SM-F766B
Form Factor
Folder (flip) - touch screen, dual screen
Protection
Water-resistant
Dimensions Details
Unfolded - 75.2 mm x 6.5 mm x 166.7 mm ¦ Folded - 75.2 mm x 13.7 mm x 85.5 mm
Body Material
Corning Gorilla Glass Victus 2, Armor Aluminium 2 frame
Technology
WCDMA (UMTS) / GSM
Mobile Broadband Generation
5G
Service Provider
Not specified
Operating System
Android 15
Intelligent Assistant
Google Gemini
Navigation
GPS, GLONASS, BeiDou, Galileo, QZSS
SIM Card Type
Nano SIM, Electronic SIM card (e-SIM)
Payment Technology
Samsung Pay
Data Transmission
FDD-LTE, TDD-LTE, 5G NR FR1
2G Band
850 GSM, 900 GSM, 1800 GSM, 1900 GSM
3G UMTS Band
Band 1, Band 2, Band 4, Band 5, Band 8
3G UMTS Frequency
2100, 1900, 1700, 850, 900
4G LTE Band
Band 1, Band 2, Band 3, Band 4, Band 5, Band 7, Band 8, Band 12, Band 13, Band 17, Band 18, Band 19, Band 20, Band 25, Band 26, Band 28, Band 32, Band 38, Band 39, Band 40, Band 41, Band 66
4G LTE Frequency
FDD 2100, FDD 1900 PCS, FDD 1800+, FDD 1700 - 2110 AWS, FDD 850, FDD 2600, FDD 900, FDD 700a, FDD 700c, FDD 700b, FDD 800 lower, FDD 800 upper, FDD 800 DD, FDD 1900+, FDD 850+, FDD 700 APT, FDD 1500 L, TDD 2600, TDD 1900, TDD 2300, TDD 2500, FDD 1700 - 2110 AWS-3
5G NR Band
N1, n2, n3, n5, n7, n8, n20, n28, n38, n41, n66, n75, n77, n78, n40, n25, n12, n26
5G NR Frequency
FDD 2100, FDD 1900PCS, FDD 1800, FDD 850, FDD 2600, FDD 900, FDD 800, FDD 700APT, TDD TD 2600, TDD TD 2500, FDD AWS-3, SDL DL 1500+, TDD TD 3700, TDD TD 3500, TDD 2300, FDD 1900, n12, FDD 850
Wireless Interface
NFC, IEEE 802.11a/b/g/n/ac/ax/be, Bluetooth 5.4
Sensors
Accelerometer, proximity sensor, barometer, gyro sensor, hall sensor, geomagnetic sensor, light sensor
Security Devices
Face recognition, fingerprint reader (side)
Additional Features
MIMO technology, Fast Charging, Samsung KNOX, Samsung DeX support, Samsung Smart Switch, dual stereo speakers, Samsung Knox Vault, 2 years of product availability from launch date, Samsung Wallet, Samsung Knox Suite, 7 years of Security Updates, Galaxy AI, Circle to Search, Note Assist, Photo Assist, Interpreter, Transcript Assist, 7 generations of OS upgrades, Samsung Health, Samsung Care+, SmartThings Support, Drawing Assist, Quick Share, Now Brief, Now Bar, Call Assist, Writing Assist, Gemini Live, Armor FlexHinge, Samsung Knox Matrix Trust Chain technology, Rich Communication Services (RCS)
Supported Digital Audio Standards
WAV, AAC, AMR, MP3, FLAC, XMF, OGG, MIDI, APE (Monkey's Audio), M4A, DSF, MXMF, OGA, 3GA, AWB, IMY, RTTTL, RTX, OTA, DFF, MID
Supported Digital Video Standards
MKV, FLV, AVI, 3GP, M4V, WebM, 3G2, MP4
Sound Enhancements
Dolby Atmos sound technology
Processor Core Qty
10-core
RAM
LPDDR5X SDRAM - 12 GB
Internal Memory Capacity
256 GB
Sensor Resolution
10 Megapixel
Focus Adjustment
Focus free
Field of View (FoV)
85 degree(s)
Camera Modes
Palm shutter
Video Resolutions
3840 x 2160 (4K) at 60 fps
Light Source
Display flash
Sensor Resolution
50 Megapixel
Optical Image Stabiliser
Optical Image Stabiliser (OIS)
Lens Type
Wide-angle lens
Field of View (FoV)
85 degree(s)
Focus Adjustment
Automatic
Camera Modes
Panorama, Slow motion mode, HYPERLAPSE, Professional mode, Food, Portrait, Night, Single Take, Dual Record, Expert RAW mode
Video Resolutions
Slo-mo video 1920 x 1080 (1080p) at 120 fps, 3840 x 2160 (4K) at 60 fps, Slo-mo video 1920 x 1080 (1080p) at 240 fps
Features
Quick Launch, real-time photo filters, Scene Optimiser, Dual preview, Auto framing, FlexCam, AI Zoom, ProVisual Engine, Photo Assist, 2x Optical Quality Zoom, Adaptive Pixel Sensor, Portrait Studio, Auto Zoom
Sensor Resolution
12 Megapixel
Lens Type
Ultra wide-angle lens
Field of View (FoV)
123 degree(s)
Technology
Dynamic AMOLED 2X
Display Resolution
2520 x 1080 pixels
Max Brightness
2600 cd/m²
Colour Depth
16.7 million colours
Enhancement Technology
Vision Booster technology
Protection
Corning Gorilla Glass Victus 2 (scratch resistant glass)
Features
Edge-to-Edge screen, AOD(Always On Display), 1-120Hz adaptive refresh rate, FlexWindow, Infinity Flex, secondary screen: 342 PPI
Type
OLED display - colour
Display Resolution
1048 x 948 pixels
Colour Depth
16.7 million colours
Connector Type
USB Type-C - 24 pin USB-C
Wireless Charging Standards
Wireless PowerShare
Battery Endurance per Cycle
2524 min
Battery Endurance in Cycles
2000
Run Time Details
Playback (wireless video): up to 31 hrs
Ingress Protection Rating
IP48
Repeated Free Fall Reliability Class
Class A
Compliant Standards
IEC 61960, USB 3.2 Gen 1, Android Audio Streaming for Hearing Aid (ASHA), IP48
Included Accessories
SIM card removal tool, USB-C to USB-C cable
Service & Support
Limited warranty - 3 years
Sustainability Information
Repairability Class
Class C
Product Recycled Content
18.2 %
Max Depth of Water Resistance
1.5 m
