Cybex SCM185DPH - KVM / audio / USB switch - 8 por

Images Manuals

Images for illustrative purposes

Cybex SCM185DPH

Name: Cybex SCM185DPH
Brand: AVOCENT
SKU: MMECD75492
Price: 1902.53 EUR
Availability: InStock

View all AVOCENT KVM Switches - Visit the AVOCENT Store (SCM185DPH-400) - (MMECD75492)

Model: Cybex

Cybex SCM185DPH - KVM / audio / USB switch - 8 ports - rack-mountable - TAA Compliant

Versatile connectivity options
Wide environmental compatibility
Robust power consumption
Regulatory compliance
Single local user access

FREE Delivery on orders over €250

1 Available to Ship
Order within 12Hrs 11Mins for: FREE Delivery (8 Jun or 9 Jun)

€1902.53 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

The Vertiv Cybex SCM185DPH is designed for efficient KVM switching with performance in both desktop and rack-mountable setups. It supports video resolutions up to 3840 x 2160 at a refresh rate of 60 Hz, ensuring image quality. With 8 ports for KVM, audio, and USB connectivity, it provides flexibility for various devices while allowing a local user to control multiple systems easily. Enhanced with features like dual view support and CAC reader compatibility, this KVM switch meets standards including FCC Class A and NIAP Protection Profile 4.0. Operating within a wide temperature range and compliant with multiple certifications, it excels in diverse environments.

Features Summary

Versatile connectivity options
Equipped with multiple interfaces, the SCM185DPH offers audio and video connectivity through DisplayPort and HDMI, along with USB ports to accommodate various peripherals.
Wide environmental compatibility
With a minimum operating temperature of 0 °C and a maximum of 40 °C, this KVM switch is suitable for a range of environments while ensuring operational reliability at humidity levels of 0 to 80% RH.
Robust power consumption
The internal power supply operates efficiently at a consumption of just 45 W, providing a stable performance across both AC 120 V and 230 V environments.
Regulatory compliance
Compliant with FCC Class A, TUV, VCCI, RCM, and NIAP PP 4.0 standards, this product ensures adherence to high-quality operational requirements and security protocols.
Single local user access
Designed for single local user access, the SCM185DPH allows for streamlined operation with enhanced control, making it ideal for dedicated work environments.

Specification Summary

Product Description

Cybex SCM185DPH - KVM / audio / USB switch - 8 ports - rack-mountable - TAA Compliant

Device Type

KVM / audio / USB switch - 8 ports

Enclosure Type

Rack-mountable 1U

Subtype

KVM

Ports

8 x KVM / audio / USB

KVM Users Qty

1 local user

Features

NIAP Protection Profile 4.0, CAC reader support, touch screen support, dual view, Dedicated Peripheral Port

Power

AC 100-240 V

Dimensions (WxDxH)

43.9 cm x 18.5 cm x 4.3 cm

Weight

2.5 kg

TAA Compliant

Yes

Manufacturer Warranty

3-year warranty

Specifications

EAN / GTIN:

0636430089676

General

Device Type

KVM / audio / USB switch - 8 ports

Enclosure Type

Desktop, rack-mountable 1U

Subtype

KVM

Ports

8 x KVM / audio / USB

KVM Local Users Qty

1 local user

Keyboard / Mouse Interface

USB

Max Resolution

3840 x 2160 @ 60 Hz

Features

NIAP Protection Profile 4.0, CAC reader support, touch screen support, dual view, Dedicated Peripheral Port

Expansion / Connectivity

Interfaces

8 x DisplayPort/HDMI input ¦ 8 x USB 2.0 Type B ¦ 8 x keyboard (USB) / mouse (USB) Type B ¦ 8 x audio / headphones phone stereo 3.5 mm ¦ 2 x DisplayPort/HDMI output ¦ 2 x keyboard (USB) / mouse (USB) Type A console ¦ 1 x USB 2.0 Type A console ¦ 1 x headphones output phone stereo 3.5 mm console

Power

Power Device

Internal power supply

Voltage Required

AC 100-240 V

Power Consumption Operational

45 Watt

Miscellaneous

Compliant Standards

RCM, FCC Class A certified, VCCI, TUV, NIAP PP 4.0, TUV C

TAA Compliant

Yes

Dimensions & Weight

Width

43.9 cm

Depth

18.5 cm

Height

4.3 cm

Weight

2.5 kg

Manufacturer Warranty

Service & Support

Limited warranty - 3 years

Environmental Parameters

Min Operating Temperature

0 °C

Max Operating Temperature

40 °C

Humidity Range Operating

0 - 80% RH (non-condensing)

Min Storage Temperature

-20 °C

Max Storage Temperature

60 °C
