APC Service Bypass Panel - bypass switch

Images Manuals

Images for illustrative purposes

APC Service Bypass Panel

Name: APC Service Bypass Panel
Brand: APC
SKU: ECE2463459
Price: 1159.75 EUR
Availability: OutOfStock

View all APC UPS Accessories - Visit the APC Store (SBP5000RMT2U) - (ECE2463459)

Service Bypass Panel - Bypass switch (rack-mountable) - AC 200/208/240 V - output connectors: 4 - 2U - 19" - 3.05 m cord - black - APC Take-Back - for Smart-UPS 3000VA USB & Serial, 3000VA XL, 5000VA, 5000VA XL

FREE Delivery on orders over €250

**Note: There may be an extra delivery charge on some very large UPS, we will notify you if this is the case. Please ensure you are buying the correct UPS or Battery, once a UPS or Battery is opened it cannot be returned. Please contact sales through email, chat or phone if you need to confirm.

0 Available to Ship
Restock 22-Jun-2026 Estimated, Out of Stock Prices are Estimated.

RRP ~~€1476.00~~

€1159.75 Incl Vat

Wishlist Compare

Overview

Range/Series Overview

IMPORTANT: This Range/Series overview section describes the range of which this product belongs. Features of different versions might be mentioned and may not apply to the specific product on this page. Please view Specs for specification of product.

APC sets the standard in its industry for quality, innovation and support. Its comprehensive solutions, which are designed for both home and corporate environments, improve the manageability, availability and performance of sensitive electronic, network, communications and industrial equipment of all sizes. The mission of APC is to improve the manageability, availability, and performance of information and communication systems through rapid development and delivery of innovative solutions to real customer problems.

This extremely reliable service bypass panel is designed for APC Smart-UPS 3-5kVA.

Specification Summary

Product Description

APC Service Bypass Panel - bypass switch

Device Type

Bypass switch - rack-mountable

Cord Length

3.05 m

Rack Size

19" - 2U

Weight

13.6 kg

Input Voltage

AC 200/208/240 V

Output Voltage

AC 200/208/240 V

Input Connectors

Power NEMA L6-30

Output connectors

2 x power NEMA L6-20 ¦ 2 x power NEMA L6-30

Colour

Black

Pricing Type

APC Take-Back

Dimensions (WxDxH)

43.2 cm x 66 cm x 8.9 cm

Manufacturer Warranty

2-year warranty

Designed For

Smart-UPS 3000VA USB & Serial, 3000VA XL, 5000VA, 5000VA XL

Specifications

EAN / GTIN:

731304212584

General

Device Type

Bypass switch - rack-mountable

Height (Rack Units)

Rack Size

19"

Cord Length

3.05 m

Colour

Black

Power Device

Input Voltage

AC 200/208/240 V

Frequency Required

50/60 Hz

Input Connectors

Power NEMA L6-30

Power Output Connectors Details

2 x power NEMA L6-20 ¦ 2 x power NEMA L6-30

Output Voltage

AC 200/208/240 V

Miscellaneous

Cables Included

Power cable 3.05 m

Rack Mounting Kit

Included

Compliant Standards

CSA, UL, GOST, EN 60950, UL 1778, IEC 60950

Pricing Type

APC Take-Back

Manufacturer Warranty

Service & Support

Limited warranty - parts - 2 years

Environmental Parameters

Min Operating Temperature

-20 °C

Max Operating Temperature

50 °C

Min Storage Temperature

-25 °C

Max Storage Temperature

65 °C

Humidity Range Operating

0 - 95%

Humidity Range Storage

0 - 95%

Dimensions & Weight

Width

43.2 cm

Depth

66 cm

Height

8.9 cm

Weight

13.6 kg

Compatibility Information

Designed For

APC Smart-UPS 3000VA USB & Serial, 3000VA XL, 5000VA, 5000VA XL
