EAN / GTIN:
0190017752013
Device Type
Switch - 8 ports - Managed
Enclosure Type
Rack-mountable, wall-mountable 1U
Ports
8 x 10/100/1000 (PoE+) + 2 x Gigabit SFP (uplink)
Power Over Ethernet (PoE)
PoE+
Performance
Switching capacity: 20 Gbps ¦ Throughput: 14.8 Mpps ¦ Latency (1 Gbps): 3.2 µs
Capacity
Packet buffer size: 12.38 MB ¦ Switched virtual interfaces (SVIs) (dual stack): 16 ¦ IPv4 host table (ARP): 1024 ¦ IPv6 host table (ND): 512 ¦ IPv4 routes (Unicast): 512 ¦ IPv6 routes (Unicast): 512 ¦ IGMP groups: 512 ¦ MLD groups: 512 ¦ IPv4 ACL entries (ingress): 1914 ¦ IPv6 ACL entries (ingress): 957 ¦ MAC ACL entries (ingress): 1914
MAC Address Table Size
8192 entries
Jumbo Frame Support
9198 bytes
Routing Protocol
IGMP, IGMPv2, IGMPv3, MLD, MLDv2
Remote Management Protocol
MIB, CLI, RMON, SNMP, SNMP 2, SNMP 3
Authentication Method
RADIUS, TACACS+, Secure Shell (SSH), Secure Shell v.2 (SSH2)
Features
PoE Class 4, CoS, ToS, TPM, Layer 2 switching, layer 3 routing, Address Resolution Protocol, LLDP, UTM, UDLD, RPVST+, RSTP support, MSTP support, security slot (Kensington security lock compatible), fanless
Compliant Standards
IEEE 802.3af, IEEE 802.3at, IEEE 802.1D, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3, IEEE 802.3ab, IEEE 802.3ad (LACP), IEEE 802.3x, IEEE 802.3az
Processor
1 x ARM Cortex-A9: 1.016 GHz
Interfaces
8 x 10/100/1000 Base-T (PoE+) RJ-45 PoE Class 4 ¦ 2 x Gigabit LAN SFP uplink ¦ 1 x USB-C console ¦ 1 x USB Type A host
Power Device
Internal power supply
Voltage Required
AC 100-127/200-240 V (50/60 Hz)
Power Consumption Stand by
10.9 Watt
Rack Mounting Kit
Included
Compliant Standards
IEC/EN 62368-1:2014, IEC/EN 62368-1:2018, UL 62368-1:2019 Ed.3, CSA C22.2 No. 62368-1:19 Third Edition, CNS 15598:2020, KC 62386-1:2021, VCCI-CISPR 32 Class A, CNS 15936 Class A, FCC CFR 47 Part 15 Class A, EN 55032:2015/A11:2020, CISPR-32 Class A, ICES-003 Issue 7: 2020 Class A, AS/NZS CISPR 32:2015 Class A, IEC/EN 60825-1:2014 Class 1, Laser Class 1, CISPR 35: 2016, EN 55035:2017/A11:2020, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, EN 61000-3-2, IEC 61000-3-2, EN 61000-3-3, IEC 61000-3-3
Localisation
English / United Kingdom
Software / System Requirements
Service & Support
Limited warranty - lifetime
Min Operating Temperature
0 °C
Max Operating Temperature
45 °C
Humidity Range Operating
5 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 90% (non-condensing)
