EAN / GTIN:
0190017663869
Device Type
Radio access point
Form Factor
Wall / ceiling mountable
Connectivity Technology
Wireless
Data Transfer Rate
3.9 Gbps
Line Coding Format
CCK, 64 QAM, 256 QAM, BPSK, QPSK, 16 QAM, OFDM, 1024 QAM, 4096 QAM, OFDMA
Data Link Protocol
IEEE 802.11b, IEEE 802.11a, IEEE 802.11g, IEEE 802.11n, IEEE 802.11ac, IEEE 802.11ax (Wi-Fi 6E), Bluetooth 5.0, ZigBee
Spread Spectrum Method
OFDM, DSSS, OFDMA
Frequency Band
2.4 GHz, 5 GHz, 6 GHz
Performance
Maximum data rate (2.4 GHz): 287 Mbps ¦ Maximum data rate (5 GHz): 1.2 Gbps ¦ Maximum data rate (6 GHz): 2.4 Gbps ¦ Aggregate data rate: 3.9 Gbps
Capacity
Wireless clients per Wi-Fi radio: 512 ¦ OFDMA units: 8 ¦ BSSIDs per radio: 16
Status Indicators
System, radio
Features
Transmit Beamforming, Passpoint Release 2, Dynamic Frequency Selection (DFS), Maximum Ratio Combining (MRC), Cyclic Delay Diversity (CDD), cyclic shift diversity (CSD), Space Time Blocking Code (STBC), Low Density Parity Check (LDPC), Trusted Platform Module (TPM), Target Wait Time (TWT), packet aggregation A-MPDU, packet aggregation A-MSDU, High-Throughput (HT) support, Very High Throughput (VHT) support, High Efficiency (HE) support, Advanced Cellular Coexistence (ACC), 2x2:2 MU-MIMO technology, Orthogonal Frequency Division Multiple Access (OFDMA), security slot (Kensington security lock compatible)
Encryption Algorithm
WPA, WPA2, WPA3-Enterprise, Opportunistic Wireless Encryption (OWE), Simultaneous Authentication of Equals (SAE)
Directivity
Omni-directional
Internet of Things (IoT) Compatible
Yes
Communications Technology
Bluetooth Low Energy (LE), Zigbee
Interfaces
2 x 100/1000/2500Base-T - RJ-45 ¦ 1 x USB 2.0 - Type A ¦ 1 x console - micro-USB
Compliant Standards
FCC, ISED, RED 2014/53/EU, EMC 2014/30/EU, LVD 2014/35/EU, UL 60950, IEC 60950, EN 60950, EN 62368-1, IEC 62368-1, EN 60601-1-2, EN 60601-1-1
Power Over Ethernet (PoE) Supported
PoE
Software / System Requirements
OS Required
ArubaOS, InstantOS
Service & Support
Limited warranty - lifetime
Min Operating Temperature
0 °C
Max Operating Temperature
50 °C
Humidity Range Operating
5 - 95%
