Host Connectivity
Gigabit Ethernet
Enclosure Type
Rack-mountable - 2U
Total Storage Capacity
96 TB
Installed Devices / Modules Qty
8 (installed) / 8 (max)
Built-in Devices
Led panel
Processors Installed
1 x AMD Ryzen Embedded V1500B 2.2 GHz
Number of Cores
Quad-Core
RAM
4 GB (installed) / 32 GB (supported) - DDR4
Interface Type
SATA 6Gb/s
RAID Level
RAID 0, RAID 1, RAID 5, RAID 6, RAID 10, JBOD
Interface Type
SATA 6Gb/s
Data Link Protocol
10Mb LAN, 100Mb LAN, 1GbE
Network / Transport Protocol
SMB, NFS, FTP, iSCSI, HTTP, HTTPs, PPTP, L2TP, SFTP, TCP/IP, IPSec, POP3, SMTP, IMAP, DNS
Remote Management Protocol
HTTP, HTTPS, SNMP, LDAP, Telnet, SSH, SFTP, TFTP, RADIUS
Network Services Compatibility
Server Message Block (SMB), Apple File Protocol (AFP), FTP, Web-based Distributed Authoring and Versioning (WebDAV), File Level Security (ACLs), Server Message Block 2.0 (SMB 2.0), Server Message Block 3.0 (SMB 3.0), Network File System v3 (NFS v3), Network File System v4 (NFS v4), Network File System v4.1 (NFS v4.1), Microsoft CIFS, HTTP, HTTPS, Calendaring Extensions to WebDAV (CalDAV), Microsoft Active Directory (AD), SFTP, DNS
Performance
Throughput (reading): 2315 MB/s ¦ Throughput (writing): 1147 MB/s
Features
Reset button, hardware encryption, Link Aggregation, failover protection, Btrfs, EXT4 file system, WOL, WOW, SSD trim, Synology Hybrid RAID, ACL support, High Availability, event log, LDAP support, download client, iSCSI LUN clone/snapshot, MailPlus server, DLNA Media Server, Photo album server, surveillance station, VPN Server, file sharing, firewall protection, backup server, Rsync compatible, file station, FTP server, cloud station server, Alibaba Cloud OSS support, Amazon S3 support, Backblaze B2 support, Baidu cloud support, Dropbox support, Google Drive support, hubiC support, MegaDisk support, Microsoft OneDrive support, OpenStack Swift-compatible, Tencent COS support, Yandex Disk support, Apple Time Machine compatible, PXE support, DNS server, RADIUS Server, anti-virus protection, white list, cloud backup, iTunes server, bandwidth control, OpenStack compatible
Encryption Algorithm
AES-NI, SSL, TLS
Compression Format
H.264, H.265
Expansion Bays
8 (total) / 0 (free) x hot-swap - 2.5" / 3.5"
Expansion Slots
1 (total) / 1 (free) x PCI Express 3.0 x8 ¦ 2 (total) / 1 (free) x SO-DIMM 260-pin
Interfaces
4 x Ethernet 1000Base-T - RJ-45 ¦ 1 x eSATA ¦ 2 x USB 3.2 Gen 1 - Type A ¦ 1 x serial (management) - DB-9
Features
Audible alarm, reset button, built-in 2 cooling fans, scheduled power on/off, wake on LAN
Compliant Standards
FCC, BSMI, CCC, EAC, KC, VCCI, RCM, RoHS
Power Device
Internal power supply
Voltage Required
AC 100-240 V (50/60 Hz)
Power Consumption Operational
49.98 Watt
Power Consumption Stand by
22.64 Watt
Software / System Requirements
Storage Operating System
Synology DiskStation Manager
OS Required
Apple MacOS X 10.12 or later, Microsoft Windows 7 or later
Service & Support
Limited warranty - 3 years
Min Operating Temperature
0 °C
Max Operating Temperature
35 °C
Humidity Range Operating
5 - 95% RH
