Device Type
Switch - 16 ports - L3 - Managed
Enclosure Type
Front to back airflow rack-mountable 1U
Subtype
25 Gigabit Ethernet
Ports
16 x 1/10/25 Gigabit SFP / SFP+ / SFP28 + 4 x 40/100 Gigabit QSFP+ / QSFP28
Performance
Switching capacity: 1.2 Tbps
Capacity
VLANs supported: 4094 ¦ IGMP groups: 7000 ¦ MLD groups: 7000 ¦ IPv4 routes (Multicast): 7000 ¦ IPv6 routes (Multicast): 7000 ¦ IPv4 ACL entries (egress): 8192 ¦ IPv6 ACL entries (egress): 2048 ¦ MAC addresses: 212992 ¦ Host table entries (IPv4): 145780 ¦ Host table entries (IPv6): 145780 ¦ IPv4 routes (Unicast): 606977 ¦ IPv6 routes (Unicast): 630784 ¦ IPv4 ACL entries (ingress): 65536 ¦ IPv6 ACL entries (ingress): 16384 ¦ MAC ACL entries (egress): 8192 ¦ MAC ACL entries (ingress): 65536
Routing Protocol
OSPF, static IPv6 routing, static IPv4 routing, IGMP, MLD, BGP-4, BGP, PIM-SM, VRRP, Bidirectional Forwarding Detection (BFD)
Remote Management Protocol
CLI, RMON, SNMP, TFTP, SFTP, NTP, DHCP
Encryption Algorithm
EAP-TLS
Authentication Method
RADIUS, TACACS+, Secure Shell v.2 (SSH2)
Features
RPVST+, VXLAN Distributed Anycast Gateway, VXLAN ARP/ND Suppression, VRF, Loopback, QoS, packet storm protection, DCB, RoCE v2, ECN, VSX, ERPS, UDLD, REST API interface, sFlow, job scheduler framework, dual flash Images, MSTP support, RSTP support, ARP support, IP Directed Broadcast
Compliant Standards
IEEE 802.3ad (LACP), IEEE 802.1ab (LLDP), IEEE 802.1D, IEEE 802.1w, IEEE 802.1s
Interfaces
16 x 1/10/25Gbit LAN SFP/SFP+/SFP28 ¦ 4 x 40/100Gbit LAN QSFP28/QSFP+ ¦ 1 x serial RJ-45 ¦ 1 x console Type C ¦ 1 x management Type A
Power Device
Internal power supply - hot-plug
Voltage Required
AC 100-127/200-240 V (50/60 Hz)
Power Consumption Stand by
110 Watt
Included Accessories
3 fan trays, rack kit (2 post)
Rack Mounting Kit
Included
Compliant Standards
EN 50581:2012, EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, EN 62368-1:2014 Second Edition, cUL No.60950-1 Second Edition, UL 60950-1 Second Edition, CSA 22.2 No. 60950-1, IEC60950-1:2005, Second edition + Am1:2009 + A2:2013, IEC 62368-1: 2014, EN 55024:2010, EN 55032:2015, EN 55035:2017, EN 61000-3-2:2014 Class A, EN 61000-3-3:2013, FCC CFR47 Part 15, ICES-003 Class A, VCCI Class A, CNS 13438, CNS 13438 Class A, FCC Class A certified, CISPR 35, CISPR 32 Class A, CISPR 24
Localisation
English / United Kingdom
Service & Support
Limited warranty - lifetime
Min Operating Temperature
0 °C
Max Operating Temperature
45 °C
Humidity Range Operating
15 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
15 - 95% (non-condensing)
