Device Type
Switch - 48 ports - L3 - Managed
Enclosure Type
Back to front airflow rack-mountable 1U
Subtype
25 Gigabit Ethernet
Ports
48 x 1/10/25 Gigabit SFP / SFP+ / SFP28 + 8 x 40/100 Gigabit QSFP+ / QSFP28
Performance
Switching capacity: 6.4 Tbps ¦ Throughput: 2000 Mpps
Capacity
IPv4 host table capacity: 120000 ¦ IPv6 host table capacity: 52000 ¦ IPv4 routes (Unicast): 131072 ¦ IPv6 routes (Unicast): 32732 ¦ MAC address entries: 98304 ¦ IGMP groups: 4094 ¦ MLD groups: 4094 ¦ IPv4 routes (Multicast): 7000 ¦ IPv6 routes (Multicast): 7000
Routing Protocol
BGP, OSPF, BGP-4, Bidirectional Forwarding Detection (BFD), ECMP, EGP, GRE, IGMP, IGMPv2, IGMPv3, Multiprotocol BGP, OSPFv2, OSPFv3, policy-based routing (PBR), RIPng, static IPv4 routing, static IPv6 routing, VRRP, MLD, STP, RSTP, MSTP, PIM-DM, PIM-SM, PIM-SSM, MSDP, MLDv2, MLDv3
Remote Management Protocol
SNMP, TFTP, SFTP, RMON, SNMP 2c, SNMP 3, SSH, SSH-2
Encryption Algorithm
FIPS 140-2
Authentication Method
Secure Shell (SSH), Secure Shell v.2 (SSH2), RADIUS, TACACS+, RADSEC
Features
Hot swappable 6 fans, 32MB packet buffer, EoR, ToR, High Availability, VRF-Lite, IPv6 support, Aruba VSF, ACL support, ARP support, BFD, BPDU, Cisco IPSLA, DCB, DCBX support, DWRR, DHCP relay, DHCP server, DNS support, dual firmware images, ETS, ECMP, ERPS, EVPN, GRE, IGMP support, IPv4 and IPv6 dual stack, Loopback, NTP, packet storm protection, port mirroring, PFC, Private VLAN, QoS, RPVST+, sFlow, STP support, SPQ, UDLD, VXLAN, VRRP support, VSX, VLAN support, fast leave, IGMP snooping, load balancing, MLD snooping
Compliant Standards
IEEE 802.1ab (LLDP), IEEE 802.3ad (LACP), IEEE 802.1ak, IEEE 802.1t, IEEE 802.1AX, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1s, IEEE 802.1w, IEEE 802.3ae, IEEE 802.3by, IEEE 802.3ba, IEEE 802.3x, IEEE 802.3z
Built-in Devices
64 GB SSD
Status Indicators
Port transmission speed
Interfaces
48 x 1/10/25Gbit LAN SFP28 ¦ 8 x 40/100Gbit LAN QSFP28 ¦ 1 x management (LAN) RJ-45 ¦ 1 x console RJ-45 ¦ 1 x console (micro-USB) Type B ¦ 1 x USB Type A
Power Device
Internal power supply - hot-plug
Power Redundancy Scheme
N+1
Voltage Required
AC 100-240 V (50/60 Hz)
Power Consumption Operational
550 Watt
Included Accessories
6 x fans
Compliant Standards
EN 60950-1:2006+A11:2009+A1:2010+A12:2011+A2:2013, IEC60950-1:2005, Second edition + Am1:2009 + A2:2013, UL 60950-1, CSA 22.2 No. 60950-1, EN 60825-1:2007, IEC 60825-1:2007 Class 1, EN 55032:2012 Class A, EN 55024:2010, EN 61000-3-2:2014 Class A, EN 61000-3-3:2013, FCC CFR47 Part 15 B Class A, VCCI Class A, CNS 13438, EN 60825-1:2014, IEC 60825-1:2014 Class 1, Laser Class 1, RoHS, EN 50581:2012
Localisation
English / United Kingdom
Service & Support
Limited warranty - 5 years
Min Operating Temperature
0 °C
Max Operating Temperature
40 °C
Humidity Range Operating
5 - 95% (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 95%
