Device Type
Switch - 12 ports - L3 - Managed - stackable
Enclosure Type
Rack-mountable 1U
Ports
12 x 10/100/1000 (PoE+) + 2 x 100/1000 (uplink) + 2 x 1 Gigabit / 10 Gigabit SFP+
Power Over Ethernet (PoE)
PoE+
Performance
Switching capacity: 68 Gbps ¦ Throughput: 50.5 Mpps ¦ Latency (1 Gbps): 3.8 µs ¦ Latency (10 Gbps): 2.9 µs ¦ Packet buffer size: 12.38 MB ¦ Stacking bandwidth: 20 Gbps
Capacity
Switched virtual interfaces (SVIs): 128 ¦ IPv4 host table capacity: 8000 ¦ IPv6 host table capacity: 8000 ¦ IPv4 routes (Unicast): 2000 ¦ IPv6 routes (Unicast): 2000 ¦ IGMP groups: 1000 ¦ MLD groups: 1000 ¦ IPv4 ACL entries (ingress): 1000 ¦ IPv6 ACL entries (ingress): 1000 ¦ MAC ACL entries (ingress): 1000 ¦ IPv4 ACL entries (egress): 512 ¦ IPv6 ACL entries (egress): 256 ¦ MAC ACL entries (egress): 512
MAC Address Table Size
32000 entries
Jumbo Frame Support
9198 bytes
Routing Protocol
OSPF, OSPFv2, OSPFv3, RIP-2, ECMP
Remote Management Protocol
SNMP 2c, SNMP 3, SNMP, CLI
Encryption Algorithm
FIPS 140-2, MD5, SSL
Authentication Method
RADIUS, TACACS+
Features
UTM, Auto MDIX, UDLD, VRRP support, Layer 2 switching, QoS, DWRR, CoS, ToS, DiffServ support, EQS, MIB, NTP, UDLD, RPVST+, BPDU, IGMP support, ARP support, DNS support, ECMP, TPM, web GUI management portal, SSM, fanless, security slot (Kensington security lock compatible)
Compliant Standards
IEEE 802.3, IEEE 802.3at, IEEE 802.3ad (LACP), IEEE 802.1D, IEEE 802.1w, IEEE 802.1p, IEEE 802.1Q, IEEE 802.1ab (LLDP), IEEE 802.1s
Processor
1 x ARM: 1.2 GHz
Interfaces
12 x 10/100/1000 Base-T RJ-45 PoE Class 4 ¦ 2 x 1/10Gbit LAN SFP+ ¦ 2 x 1000Base-T ¦ 1 x console RJ-45 ¦ 1 x console (USB) Type C ¦ 1 x USB Type A host
Power Device
Internal power supply
Voltage Required
AC 90-264 V (50/60 Hz)
Power Consumption Operational
28 Watt
Included Accessories
Rack kit (2 post)
Compliant Standards
RoHS, EN 50581:2012, WEEE, DoE Level VI, EN 62368-1:2014+A11:2017 2nd Ed., EN 62368-1:2020+A11:2020 3rd Ed., BS EN 62368-1:2020 + A11:2020 3rd Ed, UL 62368-1 Third Edition, CSA 22.2 No.62368-1 Third Edition, IEC 60950-1:2005 + A1:2009 + A2:2013, IEC 62368-1: 2014 Second Edition, IEC 62368-1:2018 Third Edition, CNS 15598-1:2020, EN 55032:2015 + A11:2020 Class A, EN 55035:2017+A11:2020, EN 61000-3-2:2019, EN 61000-3-3:2013/A1:2019, FCC 47 CFR part 15B:2014 Class A, ICES-003 Class A, VCCI Class A, CISPR 32 Ed 2.1: 2019 Class A, CISPR 35 Ed 1.0:2016, EN 60825-1:2014, IEC 60825-1:2014 Class 1, Laser Class 1, CISPR 35, IEC 61000-4-2, IEC 61000-4-3, IEC 61000-4-4, IEC 61000-4-5, IEC 61000-4-6, IEC 61000-4-8, IEC 61000-4-11, IEC 61000-3-2, IEC 61000-3-3, EN 61000-3-2, EN 61000-3-3
Software / System Requirements
Service & Support
Limited warranty - lifetime
Min Operating Temperature
0 °C
Max Operating Temperature
45 °C
Humidity Range Operating
5 - 95% RH (non-condensing)
Min Storage Temperature
-40 °C
Max Storage Temperature
70 °C
Humidity Range Storage
5 - 95% RH (non-condensing)
